Service Manual
PESMX1850004CE
Version:1903
CONTENTS
1.Specification
2.Parts Identification
3.Wiring Diagram
PAGE
3 ~ 7
Ventilating Fan
1,2
8
WARNING
This service information is designed for experienced repair technicians only and is not designed for use by
the general public. It does not contain warnings or cautions to advise non-technical individuals of potential
dangers in attempting to service a product. Products powered by electricity should be serviced or repaired
only by experienced professional technicians. Any attempt to service or repair the product or products dealt
with in this service information by anyone else could result in serious injury or death.
IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are
marked by in the Schematic Diagrams, Exploded Views and Replacement Parts List. It is essential
that these critical parts should be replaced with manufacturer's specified parts to prevent shock, fire
or other hazards. Do not modify the original design without the manufacturer’s approval.
.Please have a static electricity depletion process in place before handling these components.
. Please use gloves when handling PCB parts during the repair process.
FV-0511VK2
4.Parts List
9,10
(North America )Market
1. Specification
1
Specification for base Model fans
Exhaust
4 or 6
Model No.
Air
Direction
Voltage
(V)
Frequency
(Hz)
Duct
Diameter
(inches)
Air Volume
at 0.1 “WG
(CFM)
Noise
(sones)
Speed
(rpm)
Power (W)
Weight
Lb. (Kg)
10.1 (4.5)
Specifications for Multi Speed fans
Model No.
Air
Direction
Exhaust
Voltage
(V)
Frequency
(Hz)
Duct
Diameter
(inches)
Air Volume
at 0.1 “WG
(CFM)
Noise
(sones)
Speed
(rpm)
Power (W)
Weight
Lb. (Kg)
10.1 (4.5)
Reference performance based on HVI Procedures 915, 916, and 920. [ Standby wattage.]
FV-0511VK2
FV-0511VK2
(Plug-in
FV-VS15VK1)
HVI Certified performance based on HVI Procedures 915, 916, and 920.
50
80
110
<0.3
<0.3
920
795
722
9.9
5.1
3.1
100
90
80
70
60
50
40
30
0
<0.3
<0.3
<0.3
<0.3
<0.3
<0.3
<0.3
<0.3
889
839
795
760
751
722
707
711
7.9
6.5
5.1
4.3
3.7
3.1
2.7
2.4
<0.3
1. Specification
2
Parts for Version A
Parts for Version B
Motor Motor
Main PCB Section
11KSL2M20
[Serial No]
Back Face information
QR code
Top Cover view
Side viewSide view
Main PCB Section
0511VK2
[ Serial No ]
0511VK2
[Serial No ] M
Remark: We divide this model into Version A & Version B, because of different
motor and Main PCB Section, please put attention with identification
of parts when you request a service parts.
11VK2M200 X
[ Serial No ]
11QCL1200 X
QR code
[ Serial No ]
Motor Support Motor Support
Motor Main PCB Judgment
Version A Version A ( OK ) Work
Version A Version B ( NG ) Do Not Work
Version B Version B ( OK ) Work
Version B Version A ( NG ) Do Not Work
