Setup Guide

Getting started:

•Make sure to have enough space to unpack your turntable.

•Always unpack and set up in a clean environment.

•Please Do throw away the packaging! If you need NOT

service or want to return your product, please send it

in the original packaging including all inserts. In case of

damage due to alternative packaging your dealer cannot

guarantee a full refund.

•complete manual:

www.project-audio.com/en/product/metallica-turntable

1Unpack all items from the upper inlay.

Remove the upper inlay from the box.

Carefully remove the protective cover.

a) Anti Skating Weight

b) Flat belt (33 RPM) and round belt (78 RPM)

c) Adapter for 7“ singles / Allen keys

d) Alu Sub-Platter

e) Connect it E RCA cable

f) Power supply

g) Gloves

h) Counterweight

i) Cartridge alignment protractor

Lift the turntable out of the box.

3

4

25

Unpack the platter and felt mat.

Carefully insert the alu sub-platter (d)

axle into the bearing.

If necessary, level the turntable by

adjusting the feet.

68

7

Wrap the drive belt (b) around the at

smaller pulley and sub-platter.

9

Put the platter on the turntable.

The turntable should always be placed on

a at surface. Check with a spirit level*.

Large pulley for round belt (78 RPM)

Screw the counterweight (c) in place.

Put the felt mat and a record on the platter.

10

11

12

13

Remove tonearm twist tie.

16

Turn the front dial of the counterweight

(not the whole weight) until the ‘0’ is in line

with marker at the back of the tonearm.

Remove the stylus protection cover.

14

17

15

The tonearm should be level.

Balance the tonearm by turning the

counterweight forwards and backwards

on the rod.

Now turn the whole counterweight

counterclockwise until the scale reads 30.

18

19

Put the loop of the Anti Skating Weight (a)

in the outer notch on the tonearm post.

Connect to your hi-system and

PLAY IT LOUD!

21

20

Plug in Connect it E (e) and power supply (f).

Yellow cable marks to the amplier.

*a spirit level can be purchased separately

a)

b)

c)

d)

e)

g)

f)

i) h)

0°

Lower the tonearm with the lift.

Use the rocker-switch (located on the

bottom left ) to select the playback speed.

Left: 33RPM , Middle: Standby, Right: 45/78RPM
