1
Unpack all items.
3
Remove dust cover from the box.
5
Remove the protection covering.
6
7
8
Unpack the felt mat and the platter
from the bottom of the packaging.
9
Put the drive belt on the pulley
& sub-platter.
10
11
2
Take the small boxes from the carton.
Put the platter & felt mat on the turntable.
T1 EVO
T1 EVO Phono
T1 EVO BT
Connect to any amp with integrated phono amplier or use an
external phono preamp.
Pre-mounted Connect it E (RCA cable) included.
Possible set: Pro-Ject Speaker Box 5 S2 (bookshelf speaker)
and Pro-Ject MaiA S3 (stereo integrated amplier).
Select Line Out to connect to an amplier without a phono stage.
Select Phono Out if you have an amplier with a phono stage.
Possible set: Pro-Ject Speaker Box 5 S2 (bookshelf speaker) and
Pro-Ject Stereo Box S3 BT (stereo integrated amplier).
Use Line Out to connect to an amplier without a phono stage. Use Phono
Out if you have an amplier with a phono stage. Enjoy the warmth of vinyl
with the comfort of wireless technology.
Possible set: Pro-Ject Speaker Box 5 S2 (bookshelf speaker) and Pro-Ject
Stereo Box S3 BT (stereo integrated amplier).
Speaker cable Speaker cable
Connect it E (RCA Cable)
Speaker cable Speaker cable
Connect it E (RCA Cable)
Remove the protective tonearm inlays.
Remove tonearm twist tie.
Connect to your hi-system
and enjoy your music!
Speaker cable Speaker cable
Connect it E (RCA Cable)
Speed change on left side.
T1 EVO
Setup Guide
Getting started:
• Make sure to have enough space to unpack your turntable.
• Always unpack and set up in a clean enviroment.
• Please Do NOT throw away the packaging! If you need a
service or want to return your product, please send them in
the original packaging including all inserts. In case of any
damage in another packaging your dealer cannot guaran-
tee a full refund.
• Complete manual:
https://www.project-audio.com/en/product/t1-evo
Remove stylus protector
before playback!
How to connect your model and possible setups:
33 RPM
45 RPM
a) Connect it E (RCA cable)
Detachable cable only included with T1 EVO Phono & BT
b) Drive belt
c) Stylus pressure gauge
d) Adapter for 7“ singles
e) Allen key
f) Power supply
a)
b)
c) d)
e)
f)
4
Lift the wrapped turntable out of the box.
Beware of breaking the stylus!
