Seite 1/7
What s In The Box’
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo copying, recording, or otherwise, except as may be expressly permied by the applicable copyright -
statutes or in wring by the Publisher.
A s s e m b l y M a n u a l
Euro Adapter
Female
Euro Adapter
Male
Flexino Bazooka Set for Video Film Camera Dolly
( BZ- -FLXN 01)
Double Male Thread
Adapter
4 x Extensions
1 x L Type Allen key (Size: -5/16”)
Flexino Bazooka Setup
2
• Insert the 1st extension into the Euro (32cm)
Female Adapter, then rotate and ghten it
properly.
NOTE: A Euro Female Adapter at the base
facilitates easy aachment for addional
extensions and a ratchet lock lever for locking
the extensions in place .
• The Double Male thread Adapter has been
properly mounted on the 1st Extension.
• Insert the 2nd Extension into the Double Male
Thread Adapter, then rotate and ghten it
properly.
Assembling of Extension 1 (32cm)
Assembling of Double Male Thread Adapter (2cm)
Assembling of Extension 2
• Insert the Double Male Thread Adapter to the
1st Extension, then rotate and ghten it
properly.
3
• Mount the 4th Extension on the 3rd
Extension, then rotate and ghten it
properly.
• The 2nd Extension has been properly
mounted on the Double Male Thread
Adapter.
NOTE: The Bazooka, with its detachable
extensions, makes it fast and ultra easy for -
professional.
• The 3rd Extension has been properly
mounted on the 2nd Extension.
• Mount the 3rd Extension on the 2nd (4cm)
Extension, then rotate and ghten it
properly.
Assembling of Extension 3 (4cm)
Assembling of Extension 4 (10cm)
Produktspezifikationen
| Marke: | Proaim |
| Kategorie: | Nicht kategorisiert |
| Modell: | BZ-FLXN-01 |
