Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
A s s e m b l y M a n u a l
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo copying, recording, or otherwise, except as may be expressly permied by the applicable copyright -
statutes or in wring by the Publisher.
Hybrid Cylindrical Arm with Vesa Mount
What s In The Box’
Hybrid 75mm/100mm VESA Monitor Mount (CT-HMMT-01)
2 x 400mm Rod Post
1 x T Type Allen Key -
(Size: 3/16”)
2 x Rod Mounng Clamp
Arm Mount Adaptor
2
Monitor Mount Setup
Loosen both the (top & boom) knobs on the
producon camera cart .(Not Included)
Then, raise the pole of the camera cart
(Not Included), as shown in the image.
Loosen the knob of the rod mounng clamp
and insert it into the rod of the cart.
NOTE: The monitor mount rod can be xed
parallelly to the mast of any compable cart via
the clamping bracket with a clamping range of
38mm.
Aer inserng the rod mounng clamp into
the rod of the cart , re ghten (Not Included) -
the knob to secure it. Follow the same
process to insert another Rod Mounng
Clamp into the main rod of the cart.
Loosen the ratchet knob of the rod mounng
clamp. Follow the same process to loosen the
other rod mounng clamp.
Now, insert the rod post into the hole of the
rod mounng clamp, as shown in the images.
3
Then secure the rod post with the rod
mounng clamp using the ratchet knob.
Aer securing the rod post with the rod
mounng clamp, mount the second rod post
by screwing it into the provided thread right
above the rst rod post.
Mount the arm mount adapter on the rod
post by screwing it into the provided thread.
Then mount the Hybrid Cylindrical Arm with
Vesa Mount on top of the Arm Mount
Adapter, and secure the arm mount adapter's
knob by re ghtening it.-
Then mount the Hybrid Cylindrical Arm with
Vesa Mount on top of the Arm Mount
Adapter, and secure the arm mount adapter's
knob by re ghtening it.-
NOTE: A 5/8” Baby Pin receiver at the base of
the arm mount adapter gives you the autonomy
to rig the arm on C Stands, and Light Stands.-
To detach the Vesa Mount from the Hybrid
Cylindrical Arm, loosen the bolt, as shown in
the image.
