Seite 1/5
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Workstaon with 4U rack for Alpha Stand
Clamping Range: up to 45mm(TP ALPA W4U)- -
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo copying, recording, or otherwise, except as may be expressly permied by the applicable copyright -
statutes or in wring by the Publisher.
What s In The Box’
Workstaon with 4U Rack
Tray Holder
Mounng Bracket
4mm Allen Key
2
Feature: It features two handles on the sides to
raise, lower, or rotate the plaorm.
• To aach the Mounng Bracket to the
Workstaon with 4U Rack, remove all its
bolts using the 4mm Allen key.
Mounng Bracket Assembly
• Repeat the same process with the second
bolt.
• Insert the remaining six bolts inside the rack
and ghten them using the Allen key.
• With the help of the Allen key, all bolts of the
Mounng Bracket have been removed, as
shown in the image.
• Align both holes to aach the Mounng
Bracket to the Workstaon.
• Insert the bolt from above and ghten it
using the Allen key, as shown in the image.
• The Mounng Bracket is securely aached to
the Workstaon with 4U Rack, as shown in
the image.
3
• Loosen the clamp knob of the Workstaon
tray holder and mount it on the Alpha Stand
(Not Included).
Feature: Apart from holding the stand, sturdy
yet lightweight clamps quickly connect, adjust &
disconnect without hassle.
Tray Holder Assembly
• Aer mounng the Workstaon Tray Holder,
ghten the knob of the clamp.
NOTE: The plaorm aaches to your Alpha
stand using a Tray Holder that (Not Included)
has a pair of quick clamps with a 38 to 50mm
clamping range.
NOTE: Its tool less mounng clamps make it -
super quick to connect, adjust and disconnect
from a stand without hassle.
Feature: The workstaon can slide up/down
and rotate 360° while securely clamped to the
mast of your stand, ensuring a solid aachment.
• Your setup is ready, as shown in the image.
Feature: 4U rack mount underneath the
workstaon provides easy accessorizing with
various devices, such as ampliers, mixers,
wireless receivers, and signal processors.
