Item No. 216251 - Extension Plate
View Color
Instructions
Compatible with:
Fits all 7xx266 10.1" Cradles
Zebra ET50/51/55/56 10.1"
Important:
Self-installation instructions and advice are provided for your
convenience. It is your responsibility to determine if you have the
knowledge, skills, and physical ability required to properly perform an
installation. ProClip USA, LLC. shall have no liability for damage or
injury resulting from the installation or use of any ProClip or third
party products. It is your responsibility to ensure that all products are
installed in adherence with local laws and regulations and in such a
manner as to allow a vehicle to be operated safely and without
distraction. ProClip USA, LLC. product warranties do not cover the
installation, removal or re-installation of any product.
This Extension Plate has pre-drilled holes for the ProClip and AMPS standard.
Attention:
Carefully read all instructions and review the images before installing this product.
1. Remove existing M5 Fasteners:
The Extension Plate includes 2 longer M5 fasteners to attach directly to the
cradle. Start by removing the M5 fasteners on the side you prefer to install the
extension plate onto.
3. Tighten the Fasteners:
Using the included Allen wrench, tighten the fasteners firmly down to press the
lock washers into place and prevent the screws from moving under vibration.
2. Attach the Extension Plate:
Place the extension plate over the M5 holes and attach directly to the cradle using the
included M5 x 16 Fasteners and lock washers included with the extension plate.
4. Extension Plate Options:
The extension plate allows for the attachment of additional cradles or holders for
accessories such as a #216217 universal holder for a barcode scanner.
Produktspezifikationen
| Marke: | Proclip |
| Kategorie: | Nicht kategorisiert |
| Modell: | 216251 |
| Produkttyp: | Adapter |
| Produktfarbe: | Schwarz |
| Kompatibilität: | ET50 |
| Markenkompatibilität: | Zebra |
