Radial± Smart Sheet
Radial Engineering Ltd. • © Copyright 2018 all rights reserved • www.radialeng.com • email info@radialeng.com • Subject to change without notice • Made in Canada
Catapult ± a n a l o g a u d i o s n a k e
The Catapult RX4 and TX4 act like a typical four-channel analog audio snake; they allow
you to send mic or line-level signals from one location to another without signal loss, noise,
or interference, and without any digital audio conversion needed. What makes the Catapult
system unique is that it utilizes Cat 5 Ethernet cable, which is widely available, lightweight,
and economical. Simply connect a shielded Cat 5 cable between any two Catapult modules
and they will use the analog conductors in the cable to deliver four balanced audio lines to
any destination.
Features
• Three analog stereo inputs for keyboards
• Digital USB connection for laptop soft-synth
• Sustain footswitch and switchable effects loop
• Balanced XLR outputs for the PA and monitor
outputs for stage
Benets
• Allows you to easily interface your laptop and
soft-synth
• Eliminates the need to carry a large mixer
• Separate control for stage lets you adjust
signal as needed
• Transformer isolation eliminates hum and
buzz from ground loops
Cool Stuff
• Built-in sustain footswitch eliminates the need
to carry one
• Effects loop footswitch lets you activate delay
when soloing
• Connect MIDI gear and controllers with your
laptop
• Can be used as a high quality 24bit/192kHz
recording interface
RJ45 OUTPUT – Standard Ethernet
connection for Cat 5 cable used to send
audio to the Catapult RX module.
XLR THRU – Thru output of
XLR inputs with optional mic or
line-level transformer isolation.
Using the Catapult as a sub snake on stage:
Cleaning up the stage and lowering setup times have become
essential components in production. Use the Catapult to create zones
on stage for quick deployment.
Six Models to Choose From:
Catapult modules are available in six configurations,
with the option for mic-level or line-level transformers
to split & isolate your signals at either the transmit or
receive end of the audio snake.
Model: Part No:
TX4 Transmit Module R800 8022 00
RX4 Receive Module R800 8025 00
TX4M (Mic-level transformers) R800 8023 00
RX4M (Mic-level transformers) R800 8026 00
TX4L (Line-level transformers) R800 8024 00
RX4L (Line-level transformers) R800 8027 00
BUMPER – Used to protect the
Ethernet connectors and ground
lift switch from damage.
RJ45 THRU – Parallel connection
from XLR outputs used to feed
additional Catapult modules.
GROUND LIFT – Lifts the Cat
5 cable ground path to help
eliminate ground loop noise.
XLR INPUTS – Four inputs for
connection to balanced mic or
line-level analog audio sources.
STEEL CHASSIS –
14-gauge steel housing
with carrying handle.
Using the Catapult as a 4-channel mic splitter:
Use the Catapult TX4M to split the mics between the monitor desk and
front of house with Eclipse transformer isolation to deliver a noise-free
signal, saving hours of tedious trouble shooting.
