CU6050LN CU6100LN
Operating Instructions
Series CU Air Hose Reels
Low Pressure Model Numbers:
Reelcraft Industries, Inc. • 2842 E Business Hwy 30, Columbia City, IN 46725
Ph: 800-444-3134 / 260-248-8188 • Fax: 800-444-4587 / 260-248-2605
[email protected] • www.reelcraft.com
Form# 1168-505 Rev: 7/2018
Read the following precautions and instructions before you begin assembly or using. Keep this literature in a dry place for future
reference.
Safety Precautions:
1. Make sure incoming pressure does not exceed 250 PSI.
2. Use the proper eye protection when assembling and using the hose reel.
3. Assemble the hose reel on a clean workbench free of debris and moisture.
4. Use soap and water when checking for air leaks.
5. Do not expose fingers or hands directly to a pressurized air hose or it will result in bodily injury.
6. Keep children away from the work area.
Unpacking:
When you receive your new air hose reel, it will be mostly assembled. Check to ensure that you have received the following loose parts:
Part No.QuantityDescription
602050 1 Swivel assembly replacement
602051 1 Crank handle
Installation:
Note: You must purchase hardware and air hose for mounting your new reel. Decide where you wish to mount reel before purchasing as
the hardware needed will vary provided different locations.
1. Match handle to the link lever and attach using handle assembly.
2. Apply teflon tape or pipe compound to swivel valve then thread the valve into the reel.
3. Put the bolts (3/8” or 10mm) through 4 holes in the base of the hose reel and tighten it to ceiling/wall/floor so reel can be fastened
into compressor.
4. Apply teflon tape or thread sealant to reel’s built in supply hose fitting. Then attach this supply hose to the outlet of air compressor.
5. Apply teflon tape or thread sealant to hose fitting threads. Attach to the reel swivel valve, then feed the rest of hose through the flange
opening.
6. To avoid damaging the swivel valve, make sure to use an appropriate wrench to stabilize the swivel and hosing tightening the hose
fitting.
Quality Guarantee:
Should this reel fail to perform satisfactorily due to defect or poor workmanship within one year of purchase, return
it to your place of purchase and it will be replaced or repaired free of charge. Incidental or consequential damages
are excluded from this warranty.
Specifications:
Capacity: CU6050LN - 50’ of 3/8” hose CU6100LN - 100’ of 3/8” hose
Air Inlet: 3/8” Brass NPT Hose Outlet: 3/8” Brass NPT
Maximum Pressure: 250 PSI
