Quick Start Guide

What’s in the Box

Installation

Modern Sound For Your Classic

DIN KIT

Hardware

x

(2)

x(2)

x(2)

x(6)

Included in the

Radio Motor Box

x(2)

x(2)x(2)

x(4)

x(4)

To create the Radio Face,

plug the ribbon cable from

the push-buttons into the

display.

Carefully remove the film from the back side of

the faceplate and adhesive strips on the display.

Slide the DIN Kit brackets

up to meet the back of the

faceplate and attach them to

the Radio Motor with the small

machine screws and lock

washers. (2 screws per side)

Secure the shafts to the Radio Face with a

washer and shaft nut using a deep-well socket.

DO NOT OVER TIGHTEN. Finish the assembly

by adding the front and rear knobs on each side.

Place one spacer sleeve

on each shaft and secure it

with a shaft nut.

Add a U shaped bracket(J)

to each shaft and slide the

shafts into the Radio Face

from behind.

Place the faceplate onto

Radio Face. Be sure the

faceplate and Radio Face

are properly aligned then

press firmly to attach.

PERFORM

THESE STEPS

IN A DUST

FREE AREA

FOR BEST

RESULTS

Plug the ribbon cable from the

Radio Motor into the display.

Attach the Radio Face (display

and push-buttons) to the Radio

Motor using the six small screws

from the orange bag found in

your Radio Face box.

[email protected] | help.retromanufacturing.com

3

4

5

6

Insert the DIN Sleeve into your dash opening.

Using a screwdriver, push down the tabs on all four sides of the DIN Sleeve

that align with the dash to secure it into the dash opening. You will not need to

use all of the tabs, only those that align with your dash.

L

O

O

K

F

O

R

T

H

E

O

R

A

N

G

E

B

A

G

!

R

A

D

I

O

F

A

C

E

S

C

R

E

W

S

I

J

L

K

M

N

N

OP

H

H

D

D

II

JJ

MM

L

L

M

M

EE

FF

P

K

K

Connect the Control Shafts

on each side to the Radio

Motor.

x(4)
