Features

Rocstor introduces the Type-C 7-in-1 Portable Dock, an essential companion featuring

an array of ports to enhance connectivity for your devices. With HDMI, DisplayPort, 2

USB-A, Type-C data, Ethernet, and Type-C PD charging female ports, this hub oers a

comprehensive solution for extending the capabilities of your Type-C or Thunderbolt

host devices, catering to those with a single Type-C port. Powered by advanced DP1.4

Alt mode supported IC technology, our dock delivers unparalleled performance.

Experience stunning visual output with HDMI video up to 8K/30Hz and DP video up to

8K/30Hz, while seamlessly transferring data at speeds of up to 5Gbps with USB 3.2

gen1 compatibility. Connectivity is further enhanced with 2 USB-A and Type-C data

ports, enabling simultaneous connection of up to 3 USB devices. Stay connected with

Gigabit Ethernet, ensuring seamless internet browsing. Additionally, our Type-C PD

charging port supports lightning-fast charging up to 100W, providing power when

you need it most. Compatible with all DP Alt mode supported Type-C hosts, our

portable dock oers unmatched versatility and performance for all your connectivity

needs.

Before attempting to use this unit, please check the packaging and make sure the

following items are contained in the packaging:

• Main Unit x1

• User Manual

Type-C Male X1 Host Computer

Upstream:

• Support DP1.4 Alt mode

Downstream:

• Supports max 8K/30Hz video output

• Supports High Dynamic Range(HDR)

• Supports multiple color formats: RGB;

YCbCr4:4:4; YCbCr4:2:2; YCbCr4:2:0

8/10/12 bpc;

• Supports HDCP2.3&1.4

• Supports HPD

HDMI X1

• Max 5Gbps data transmission

• Max 1.5A downstream charging

• Support short-circuit, over-current,

over-voltage protection

Type-C Data X1(Close to USB-A)

• Supports max 8k/30Hz video output

• Supports High Dynamic Range(HDR)

• Supports multiple color formats: RGB;

YCbCr4:4:4; YCbCr4:2:2; YCbCr4:2:0；

8/10/12 bpc;

• Supports HPD

• Supports Dual 4K/30Hz simultaneously

on windows system under MST mode

• Supports Dual 4K/60Hz simultaneously

on Mac OS system under SST mode

Note:The actual output resolution of the

product is determined by the host and

the display together. The product worked

on some hosts that support DP1.4&DSC

can output dual 4K/60Hz simultaneously

with dierent pictures

DisplayPort X1

• Supports Gigabit Ethernet,

10M/100M/1000M

• Supports Wake-On-LAN

• Supports full duplex ow control

• Light indicates the state, no light when

no Internet connected, orange light

turns on when network connection is

established, green light ashes when

transmitting data.

RJ45 X1

• Supports PD3.0 with max 100W PD

charging,max 85W PD charging for PC

(15w is dedicated to the functioning of

this product)

• Supports fast role swap of PD3.0, the

connected device will not get

disconnected while plugging out

PD Adapter

Type-C PD Charging X1

(Close to SD card slots)

• Max 5Gbps data transmission per port

• The port close to Type-C data port

supports max 1.5A downstream

charging, another USB-A port supports

max 900mA downstream charging

• 2 USB-A ports and the Type-C data port

share max 12W

• Supports short-circuit, over-current,

over-voltage protection

USB-A X2

Package Contents

SpecicationIntroduction

Input/Output Connector

Power Supply

Warranty

Limited Warranty3 Years

Physical

Weight4.4lbs (127g)

Size4.4x2.1x0.5in (112x55x13.2mm)

User Manual

Accessory Adapter

English Version

Certications

Regulatory Approvals

FCC, CE

Operating Temperature

Storage Humidity

Storage Temperature

Operating Humidity

0°C to 45°C (32°F to 104°F)

10% to 90 % RH (no condensation)

-10°C to 70°C (14°F to 158°F)

10% to 90% RH (no condensation)

Environmental

Operating Temperature

InputType-C Male x1

OutputHDMI x1

DP p1-x1

Type-C Data x1

USB-A x2

RJ45 x1

Type-C PD Charging x1

Type-C PD ChargingMax 100W

®

USB-C Dual Display Portable Dock Multiport Adapter

with DP 1.4 Alt Mode – USB-C 100W PD

User Manual

Y10P029-S1

Congratulations

Thank you for purchasing this premium Rocstor product. For optimum performance and

safety, please read these instructions carefully before connecting, operating or using this

product. Keep this manual for future reference.
