ROYAL SOVEREIGN INTERNATIONAL, INC.

2 Volvo Drive Rockleigh, NJ 07647 USA

TEL : +1) 800-397-1025

FAX : +1) 201-750-1022

RS CANADA INC.

5610 Timberlea Blvd, Mississauga Ontario L4W 4M6

CANADA

TEL : +1) 905-461-1095

TF # : +1) 866-961-6673

FAX : +1) 905-461-1096

IV. Specification

ModelRCD-4000D

Operating temperature50~104°F (10~40°C)

Relative humidity40~80%

Power supplyAC100~240V 50/60HZ

Net weight0.8 lbs. (375g)

Overall dimensions4.6" x 5.2" x 6.1" (118mm×132mm×155mm) (L x W x H)

I. Installation Instructions

Machine installation sequence as shown above fig.

Machine installed in sequence as shown in the

diagram on the wall.

II. Function Keys

NOFUNCTION

1Power Switch

2Mode

3Brightness Control/+Key

4Contrast Control/-Key

M

500

200

100

50

20

10

102050

1001100

5

5

10

20

20

20

20

20

50

CA Dollar IR Images

US Dollar IR ImagesGBP IR Images

Euro IR Images

52010

50100

Currency Guide

III. Operation

Plug in power cable and turn power switch on. Wait 2 seconds for screen to clear. Place bill or document you would

like to verify on table under display. Refer to the currency guide for location of hidden infrared features on your

bill. Hold down power button for 2 second to turn unit off. (Fig.1)

1. Mode Selection

Press “MODE” key once, LCD will show solid character “M” as right fig. It will show the image under two different

wavelengths (850 and 940) on the screen. (Fig.2)

Fig.1

Fig.2

3. Contrast Control

Press Contrast Control key and rectangular bar will appear on the screen.

Press the + or - key to adjust the contrast level. (Fig.5)

Fig.3

Fig.4

Fig.5

Press “MODE” key twice, LCD will show hollow character “M”as right fig. Then there is only one infrared

wavelength.(Fig.3)

2. Brightness Control

Press Brightness Control key and rectangular bar will appear on the screen.

Press the + or - key to adjust the brightness level. (Fig.4)

RCD-4000D

INFRARED DETECTOR

Owner's Manual

Royal Sovereign International, Inc.

2014.08

Please read and retain these instructions.

To register your product,

please go to

www.royalsovereign.com

USA.

Click the customer Support Tab, then Registration Tab.

www.royalsovereign.com

V. Limited One Year Warranty

This warranty applies to repair or replacement of product found to be defective in material or workmanship for

three years from the date of the original purchase. This warranty is extended only to the original purchaser.

This warranty does not apply to damage resulting from abuse, misuse, or improper maintenance or damage that

is attributable to acts of nature. Royal Sovereign International, Inc. (and its affiliated companies) is not liable for

incidental or consequential damages of any nature. This limitation would not apply if you live in those areas that

do not permit the exclusion or limitation of incidental or consequential damages.

Defective products for warranty repair or replacement cannot be returned without a Return Authorization number.

Please go to www.royalsovereign.com USA-Customer Support Tab to make a request for an Office Product Return

Authorization.

Defective products must be returned to Royal Sovereign International Consumer Return Department, freight

prepaid, with proof of purchase and Return Shipping and Handling payment (check or money order). Upon repair

or replacement the product will be returned to the customer.

Return defective product to the following address with a detailed description of the problem. If possible, pack in

original carton. Please prepay shipping charges.

For out of warranty service or frequently asked questions please go to www.royalsovereign.com USA- Customer

Support Tab.

For sales of product, parts or accessories please visit us at www.royalfulfillmentcorp.com.

For service or sales please contact your local Royal Sovereign Office:
