1

1. Package content:

• Mini wireless keyboard

• 2.4 GHz receiver

• USB-A - USB-C cable

• Li-ion battery

• User manual

2. Basic information:

SAVIO KW-04 BT + 2.4 GHz wireless keyboard is a multifunctional, compact de-

vice that combines the features of a full-size QWERTY keyboard and a touch

panel (touchpad). Thanks to the KW-04 keyboard, you can browse the Internet

websites or use installed applications in a quick and easy way.

3. Device compatible with:

• PC computer / Laptop

• Windows / Linux

• Smart TV / Android TV

• TV BOX

• Xbox / PlayStation*

• Projector with Android

• Smartphone / Tablet (OTG)**

* When using the keyboard with a console, certain features such as the touch-

pad or connection type may be limited.

** Smartphones and tablets need to have an OTG function (connection by USB

OTG cable).

4. Indicator diodes description:

• LED (Blue light): indicates the operating or battery status. If it lights up

continuously, it means that the device is in working mode. If the blue light is

off, it means that the keyboard has gone into auto sleep mode, if it ashes

slowly, it means that the keypad needs to be recharged.

• LED (Red light): indicates the charging status. After connecting the

charging cable, the red light will turn on.

• LED (Orange light): indicates the connection status of the device. It

ashes rapidly when connecting to a 2.4 GHz receiver or Bluetooth. When

correctly connected, it ashes with every command sent from the key-

board (key press or touchpad).

5. Touchpad use:

The integrated touchpad enables to browse the Internet websites and use of

the installed application same way, as with a traditional computer mouse.

• Single touch of touchpad replaces the click of the left mouse button.

• Double click of the touchpad replaces the right mouse click.

• To use the scroll function, you need to use two ngers, one should be held

still on the touchpad and the other will move up and down.

Operation

mode

Single nger click

One nger drag

Two ngers click

Function

Left mouse buttonScroll up and down

(the mouse wheel)

Right mouse button

6. Connecting the device:

6.1 Connection with 2.4 GHz receiver:

6.1.1Connect the 2.4 GHz receiver to the USB port on your computer. The

2.4 GHz receiver is located under the battery cover on the back of the

keyboard.

6.1.2Turn the keyboard on by moving the switch located on the back cov-

er of the keyboard to the ON position.

6.1.3The device pairs automatically.

6.1.4When device is in the Bluetooth mode use combination to Fn + 2.4G

switch to 2.4 GHz mode.

6.2 Connection with Bluetooth:

6.2.1Turn the keyboard on by moving the switch to the ON position. The

switch is located on the back cover of the keyboard.

6.2.2To pair your device to the keyboard via Bluetooth for the rst time,

press and hold Fn + BT for 3 seconds. The orange LED will start ashing

indicating that the device is ready for pairing.

6.2.3Turn on the Bluetooth on your device (e.g. computer), choose SAVIO

KW-04 keyboard from Bluetooth devices on the list and click to pair.

6.2.4When device is working in 2.4 GHz mode, use combination to Fn + BT

switch to Bluetooth.

Note:Nowadays most wireless devices operate at 2.4 GHz. Therefore, it is

sometimes necessary to bring the keyboard close to the USB receiver for a

correct connection.

7. Auto sleep mode and wake up:

• Keyboard has the functions of automatic sleep mode and wake up.

• Keyboard automatically switches into the sleep mode within 3 minutes

when idle. Pressing any button will cause the keyboard to wake up instantly.

8. Technical specication of the keyboard:

• Bluetooth version: 5.2

• Range: up to 10 meters

• Battery capacity: 300 mAh, 3.7 V

• Power consumption: 8-15 mA, <15 mA in sleep mode

• Frequency bands in which the radio equipment operates: 2400 – 2483.5 MHz

• Maximum radio-frequency power transmitted in the frequency band in

ENGLISH

Wireless keyboard

model: KW-04

User manual

Thank you for choosing Savio product!

If our product meets your expectations, share your opinion with other people

on the portal ceneo.pl, social media or on the website of the store where you

made the purchase. If you want to show our device on SAVIO Facebook Page,

we will be very pleased.

If there is something that we could improve on our products, please write to us

at support@savio.pl

Thanks to your feedback, we will be able to better adapt the product to your expec-

tations.

Before starting the use of purchased device it is recommended to read the

whole manual.

which the radio equipment operates: 5 dBm

• Dimensions: 146 × 96 × 15 mm

• Weight: 115 g

• Number of keys: 82

9. Button programming:

The KW-04 keyboard supports up to six programmable keys that can be pro-

grammed to reproduce to the TV remote control buttons, including: power, TV

and four colored buttons on the keyboard (red, green, yellow and blue).

9.1 Press and hold the appropriate button to be programmed until the indi-

cator light is constantly on.

9.2Release the programmable button, the indicator light will ash. The next

step will be to program the appropriate button on the TV remote control.

9.3Bring the TV remote control close to the KW-04 infrared transmitter,

making sure that the distance between them is less than 5 centimeters.

Then press the corresponding button on the TV remote control, indicator

light ashes quickly: means the button has been successfully pro-

grammed. If necessary, repeat the steps from the beginning.

9.4Repeat the above steps to program the remaining buttons.

10. Reseting programmed buttons:

Press and hold + for a few seconds until the light: Fn ashes ve times

to restore factory settings.

Note:Please remember that the programmed buttons must correspond ex-

actly to the buttons on the TV remote control.

11. Diagram of key combinations:

Key

combination

Fn

+

Fn

+

Prtsc

Win

Fn

+

Fn

+

Fn

+

FN

+

Function

Sensor

sensitivity

settings

Print

screen

Backlight

options

settings

Keyboard

combi-

nation:

CTRL + ALT

+ DELETE

Main

browser

Google

Assistant

12. The backlight colour setting of the keyboard:

12.1 Press + , to activate the keyboard backlight.Fn

12.2 Press + , to get to the backlight colour setting.Fn

12.3 Conrm the backlight color by selecting the appropriate option. The

highlight color has now been saved. If you turn off the device, the key-

board will return to the basic backlight version.

13. Charging the keyboard:

13.1Connect the power cable to the USB-C socket in the keyboard (LED diode

will light up in red colour).

13.2If the LED diode will go off, it means that the keyboard is fully charged.

13.3. Plug off the power cable, the keyboard is ready to use.

14. Safety conditions:

• Use this device as intended.

• Incorrect use of the device may damage the device.

• Independent repairs and modication results in automatic loss of the warranty.

• Hitting or dropping the device could cause damage of the device.

• The device should be used in dry area, the device should be protected

from water and high humidity.

• Before the rst use of the keyboard, it should be fully charged

• After the battery is fully charged, plug off the power cable.

• If the power cable is plugged when the keyboard is fully charged, it may

cause damage to the battery or shorten its lifespan.

• When the device is not being used for a long period of time, the battery may discharge.

1. Zawartość opakowania:

• Mini klawiatura bezprzewodowa

• Odbiornik 2.4 GHz

• Kabel USB-A – USB-C

• Akumulator li-ion

• Instrukcja obsługi

2. Informacje podstawowe:

Bezprzewodowa klawiatura SAVIO KW-04 BT + 2.4 GHz to wielofunkcyjne,

kompaktowe urządzenie, łączące w sobie cechy pełnowymiarowej klawiatury

QWERTY oraz panelu dotykowego (touchpad). Dzięki klawiaturze KW-04 można

w szybki i wygodny sposób przeglądać strony internetowe oraz korzystać z

za-

instalowanych na urządzeniu aplikacji.

3. Urządzenie kompatybilne z:

• Komputer PC / Laptop

• Windows / Linux

• Smart TV / Android TV

• TV BOX

• Xbox / PlayStation*

• Projektor z Androidem

• Smartfon / Tablet z funkcją (OTG)**

* W przypadku użytkowania klawiatury z konsolą pewne funkcje takie jak to-

uchpad lub rodzaj połączenia mogą być ograniczone.

** Smartfony i tablety muszą posiadać funkcję OTG (połączenie za pomocą

kabla USB OTG).

POLSKI

Klawiatura bezprzewodowa

model: KW-04

Instrukcja obsługi

Przed przystąpieniem do korzystania z zakupionego urządzenia zaleca się

przeczytanie całej instrukcji obsługi.

Dziękujemy za zakup produktu marki Savio!

Jeśli nasz produkt spełnił Twoje oczekiwania, podziel się swoją opinią z inny-

mi osobami na portalu ceneo.pl,w mediach społecznościowych lub na stronie

sklepu, w którym dokonałeś zakupu. Będzie nam niezmiernie miło, jeśli zechcesz

również pochwalić się naszym urządzeniem na prolu SAVIO na Facebooku.

Jeśli jest coś, co moglibyśmy poprawić w naszych produktach, napisz nam

o tym na adres: [email protected]

Dzięki Twojej opinii będziemy mogli jeszcze lepiej dopasować produkt do Twoich

oczekiwań.
