Seite 1/6
Right pair - Red Blac k
Cable hanging bracket
Mounting bushing
FP Stem
Do t c or l r r t , n no spe instal speake ne a suppor beam ventilatio
duc othe structu tha ma interfe wit speake functiot or r re t y re h r n
or di pe io s rs n.
gninraWgninraW
S o u n d u b s p e a k e r m u s i n s t a l l e o f e s s i o n a a u d iT e s t b e d b y a p r l o
installer/contracto Fo safet an fo optimu audi performancer. r y d r m o ,
in taller st follo all di ectio sued by Sounds mu w r ns is Tube Entertain ent m .
Install Instructions For:
FP6030-II and FP6020-II speakers
1.435.647.9555
|
800.647.TUBE
|
www.soundtube.com
Box contents
FP Series
Signal wire/hanging cable ( 5m /15 ft) 4.
CAT V cable
Dome clamp
FP dome
High pass filt ser witch (on position)
L t p r - ef ai White Green
Right pair - R B ked lac
Left pair - White G n ree
Left pair - Green White
Right pair - R B ked lac
© 2
0 undTu22 So be Ent ta me . er in nt, Inc Allrights reser PN INS-FP6ved. REV 6.14.22
Mono Operation:
Series - 16 Ohm
Parallel - 4 Ohm
Source
ecruoSecruoS
1 FP pod w/signal wire/hanging cable
1 FP stem
1 FP Dome clamp
1 Cable hanging bracket
1 Mounting bushing
1 FP dome (in separate box)
FP speaker pod
Install Instructions For:
FP6030-II and FP6020-II speakers
1.435.647.9555
|
800.647.TUBE
|
www.soundtube.com
FP Series
Hang dome 1.5 to 2.0 feet above listener.
Hanging height Guidelines
Guidelines for setting the SP L
1. s b t n sMea ure am ien oi e level of the venue at the iebus st time.
2. n und dSta d er the ome a d se vol e len t um vel o t + d6 B above het
am ient noib se level meas reu ment.
3. t dStep ou si e t dom c the e and heck o ee s t t t Sha he PL of the
Dom s n te i ot oo lo as co pared to he aud m t mbie oint n se level.
4. u Equ zat nAdj st ali io to h the promatc gram music b yeeing pla d.
*Note - Bass fre en ies qu c will leeb d outside t mhe do e due ot
their lon er g wav helengt s.
5. u SAdj st PL as nece ar el ss y. Thi les v w based uill vary pon the
height he of t dome.
1.5 ft t fto 2.0
45.72 c to 60 96 cm . m
1. 2. Unpack FP speaker pod Thread signal wire through
stem with the smaller side
facing the pod.
3. Hand tighten stem onto
pod.stem, and dome.
4. Thread signal wire through
hole in dome and dome clamp.
5.
8. Connect signal wire
to audio source.
Note - For Mono operation see
diagram on reverse side.
7. To use hanging cable:
Attach mounting bushing
to cable hanging bracket.
Thread signal wire thru
mounting bushing, adjust
height of dome and tighten
bushing.
9. Adjust audio level
for ambient sound levels.
See chart below for
recommended levels.
Hand tighten dome clamp . 6. To use junction-box w/
face plate (not supplied):
Attach mounting bushing to
J . -box Thread signal wire thru
mounting bushing, adjust height
of dome and tighten bushing.
10. Turn high pass filter on
or off. When isw tc “uh i in s p”
posi iont , s e. si al ign fu ngll-ra
Note - In fu ge, basll-ran s freque ienc s
will blee ou ide the d ts dome due
to their lo ger n wavelengths.
Cat 5 Wiring
All signal and control wires are located in the signal/hanging cable provided
with the FP unit speaker wires. A Cat 5 cable (blue or gray shield) contains the control and power
wires; audio wires are individual 16-gauge wires in the bundle.
Wiring Instructions
1 FP-Motion module
5 Pairs audio relay jumpers
Contents
Power External controller LED Light
Speaker
Contact closure = Green/White
Contact closure = Green
12 V trigger = Blue/White
LED control = Orange/White
LED control = Orange
Left in = White
Left in = Green
Right in = Red
Right in = Black
Power = Brown/White
Power ground = Brown
FP pod [2]
Motion sensor trim pot [6]
Pod cover [1]
Motion sensor module
Motion sensor
wide aperture [5]
Audio relay [7]
(ships with motion sensor only)
Motion sensor narrow aperture [4]
Main electrical board
Motion sensor connection
Amp, audio relay or continuous
audio jumper connection
Continuous audio jumpers [8]
FP modules ship pre-installed
from the factory.
Other FP Series optional
modules include:
1. LED Light
All modules require a power source.
An optional 15 volt source is
available from SoundTube
(Model number: AC-PS-1530)
FP Series
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
Warning
© 2
0 So22 undTube Ent rtai mene n t, In . c All rig s reserve . -MOht d PN INS-FP TION REV 6.14.22
Warning
SoundTu s m in a pr s s r n r. s y r be peakers ust be stalled by ofes ional audio in talle /co tracto For afet and fo
optim dio performance, staller mu follow all di ection sued So ndum au in st r s is by u Tube te tai me En r n nt.
435.647.9555
| | 800.647.TUBE
www.soundtube.com
435.647.9555
| | 800.647.TUBE
www.soundtube.com
Ins ntall I stru tionc s For:
FP-Motion
FP Series
Pod cover screws [3]
