RS4-EZ, RS400i, RS500i, HP590i, RS600i, HP690i, RS800i, RS1201i, HP890i, RS1001i-II, HP129a,

& HP1290i speakers

Box contents

1 Speaker

2 SpeedClamps™

1 Release key (small hex wrench)

1 Hanging cable

1 Safety cable

1 Terminal weather boot

1 Euroblock connector

1 Grille-mounted tap switch cover

4 Zip ties

S y caafet ble with clip

Te mir nal w eatherboot

Signal wire

Euroblock c r onn toec

S uur cefa -mo nt

b et rack insert

Euroblock jack

Hanging ca leb with clip

H iang ng or sa tyfe cab le

S e a r ecur ncho po nti

S epe dCl mpa ™

G le ted ril -moun

tap switch co ver

(except RS4-EZ)

RS4-EZ & RS400i tap location

Tap sw ch it

Eurob ockl jack

RS400i, RS500i, RS600i ,, RS800i RS1001i-II, HP690i and HP890i - UL liste 0d 148

1.435.647.9555

800.647.TUBE

www.soundtube.com

Do not spec or install speaker near support beam, ventilation duct or

other structure that may interfere with speaker function or dispersion.

Warning Warning

SoundTube speakers ust be stalled by ofe sional audio in taller/contracto m in a pr s s r. s y and r For afet fo

optim dio performance, talle follow all di ection sued Souum au ins r must r s is by ndTube Ente tai ment r n .

RS & HP Series

Speaker 1

Speaker 2

Source

1. Select the tap position by

removing the rubber plug on

grille to access rotary switch.

Switch is preset to maximum

tap setting in 70.7 V mode.

Select desired setting and

reinsert rubber plug. Note: The

grille-mounted tap switch

cover is keyed; be sure flat

edge of plug lines up with flat

edge of hole in grille.

2. Slip terminal weather

boot over signal wire. For

environmental applications,

put RTV silicone around

nipple and base when

installation is complete.

3. Conne sict gnal wire to

4-pi uro loc pln E b k ug. Tighten

unused termin ws. Useal scre

in de sit a neg vesi po ive nd ati

inputs for either voice rcoil o

d t buted sy e . is ri st ms For aid sy

c ning o idhai , use uts e positive

and negative n termi als.

9. Attach hanging cable to

the center hole in the

speaker hanging bracket.

11. Insert 4-pin Euroblock

plug into Euroblock jack on

rear of speaker. Connectors

are keyed for polarity.

12. Use zip or twist-lo ieck t s

to se urec safety cable & signal

wire to main hangi cabng les.

Ca leb cover available fo r

as het tic applications (SLT-10).

5. Thread hanging or safety

cable through SpeedClamp™

mechanisms as shown.

7. Thread cable end(s)

through SpeedClamp™

mechanisms as shown.

6. Attach the hanging cable

by securing it and safety

cable to structure as shown.

10. At ach t the safety cable to

one of the secondary holes in

the hanging bracket.

8. Adjust speaker hanging

height with SpeedClamp™

mechanism. Pull to tighten &

insert release key (small hex

wrench) into SpeedClamp ™

as shown to loosen or adjust.

SoundTube also provides optional surface mount brackets for both the RS and HP lines of products.

Installation instructions for these accessories are included with specific accessory packaging.

4. When daisy chaining, wire

the outside terminals to the

inside terminals of the next

speaker. This step only applies

to tap settings using the

transformer and not when the

speaker is used on bypass.

RS4-EZ, RS400i, RS500i, HP590i, RS600i, HP690i, RS800i, HP890i, RS1001i-II, HP129a, & HP1290i speakers

RS & HP Series

Produktspezifikationen

Marke:	SoundTube
Kategorie:	Lautsprecher
Modell:	HP129A
Gewicht:	18210 g
Empfohlene Nutzung:	Haus
Produktfarbe:	Schwarz
Übertragungstechnik:	Kabelgebunden
Impedanz:	8 Ohm
Höhe:	452.1 mm
RMS-Leistung:	150 W
Verpackungsbreite:	533.4 mm
Verpackungstiefe:	533.4 mm
Verpackungshöhe:	565.15 mm
Zertifizierung:	CE, RoHS, UL1480A, UL2239
Menge pro Packung:	1 Stück(e)
Verpackungsart:	Box
Gehäusematerial:	Acrylnitril-Butadien-Styrol (ABS)
Audio Kanäle:	- Kanäle
Frequenzbereich:	73 - 19000 Hz
Woofer:	Ja
Tieftönerdurchmesser (imperial):	12 "
Hochtöner:	Ja
Hochtönerdurchmesser (Imperial):	1.375 "
Durchmesser:	457.2 mm
Lautsprecherplatzierung:	Deckenmontage möglich
Anzahl der Hochtöner-Antriebe:	1
Anzahl der Tieftöner-Antriebe:	1
Lautsprechergehäuse:	Portiert
Hochtönerdurchmesser:	34.9 mm
Empfindlichkeit:	97 dB
Übergangsfrequenzen:	2200 Hz
Tieftönerdurchmesser:	304.8 mm
