Seite 1/2

Box contents
1 Speaker
2 SpeedClamps™
1 Release key (small hex wrench)
1 Hanging cable
1 Safety cable
4 Zip ties
Tap sw ch it
© 2021 MSE A uudio So ndTube te tain En r men In t, c. All rights rese ved.r PN INS-MM Rev 11.15.21
UL Liste 0Ad 148
1.855.663.5600
|
www.soundtube.com
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
Warning Warning
SoundTube speakers ust be stalled by ofe sional audio in taller/contracto m in a pr s s r. s y and r For afet fo
optim dio performance, talle follow all di ection sued Souum au ins r must r s is by ndTube Ente tai ment r n .
MM43-BGM and MM32-EZ speakers
Mighty Mite
™
by
S y ca afet blewith clip
Hanging ca leb with clip
H iang ng or sa tyfe cab le
S e a r ecur ncho po nti
S epe dCl mpa ™
Transformer Taps
70.7 V
30 W
15 W
7.5 W
3.75 W
Output
98.5 dB
95.5 dB
92.5 dB
89.5 dB
100 V
30 W
15 W
7.5 W
Output
98.5 dB
95.5 dB
92.5 dB

© 2021 MSE A uudio So ndTube te tain En r ment, Inc. All rights rese ved.r PN INS-MM Rev 11.15.21
10. Use zip or twis st-lock tie
to secure safe cab &ty le signal
wire to main han ging cables.
Ca leb cover available for
as het tic applications (SLT-10).
7. Adjust speaker hanging
height with SpeedClamp™
mechanism. Pull to tighten &
insert release key (small hex
wrench) into SpeedClamp ™
as shown to loosen or adjust.
6. Thread cable end(s)
through SpeedClamp™
mechanisms as shown.
5. Attach the hanging cable
by securing it and the safety
cable to structure as shown.
8. Attach hanging cable to
the center hole in the
speaker hanging bracket.
MM43-BGM and MM32-EZ speakers
Mighty Mite
™
by
1.855.663.5600
|
www.soundtube.com
9. Att tach he safety cable to
one of the secondary holes in
the hanging bracket.
4. Thread hanging or safety
cable through SpeedClamp™
mechanisms as shown.
2. Conne sict gnal wire to
screw-down terminal block.
Tighten use min un d ter al
screws. Use in de sit si po ive
a neg ve inp nd ati uts for
either oice v r coil o
d t buted sy e . is ri st ms
Source
3. When daisy chaining, wire
the outside terminals to the
inside terminals of the next
speaker. This step only applies
to tap settings using the
transformer and not when the
speaker is used on bypass.
1. Remove the
magnetically-attached grille
from the front of the speaker to
reveal the rotary tap switch.
Select tap position on rotary
switch. Switch is preset to
maximum tap setting in 70.7V
mode.
Produktspezifikationen
Marke: | SoundTube |
Kategorie: | Lautsprecher |
Modell: | MM32-EZ |
Gewicht: | 5780 g |
Produktfarbe: | Schwarz |
Übertragungstechnik: | Kabelgebunden |
Höhe: | 556 mm |
Energiequelle: | AC |
RMS-Leistung: | 25 W |
Zertifizierung: | CE |
Menge pro Packung: | 1 Stück(e) |
Verpackungsart: | Box |
Gehäusematerial: | Acrylnitril-Butadien-Styrol (ABS) |
Durchmesser: | 188 mm |
Lautsprecherplatzierung: | Deckenmontage möglich |
Übergangsfrequenzen: | 100 Hz |
Lautsprechertyp: | 2-Wege |
