Seite 1/2
RS1201i-SuperT™
Box contents
1 Speaker
2 SpeedClamps™
1 Release key (small hex wrench)
1 Hanging cable
1 Safety cable
1 Terminal weather boot
1 Euroblock connector
1 Grille-mounted tap switch cover
4 Zip ties
S y caafet ble with clip
Te mir nal w eatherboot
Signal wire
Euroblock c r onn toec
S uur cefa -mo nt
b et rack insert
Euroblock jack
Hanging ca leb with clip
H iang ng or sa tyfe cab le
S e a r ecur ncho po nti
S epe dCl mpa ™
G le ted ril -moun
tap switch co ver
(except RS4-EZ)
© 2008 So nd u Tube te tain En r ment, Inc. All rights rese ved. PNr IN RevS-RS1201i 2.18.20
RS1201i-SuperT™
913.663.5600
|
800.647.TUBE
|
www.soundtube.com
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
Warning Warning
SoundTube speakers ust be stalled by ofe sional audio in taller/contracto m in a pr s s r. s y and r For afet fo
optim dio performance, talle follow all di ection sued Souum au ins r must r s is by ndTube Ente tai ment r n .
RS1201i-SuperT
™
Speaker 1
Speaker 2
Source
1. Select the tap position by
removing the rubber plug on
grille to access rotary switch.
The tap switch has 2 settings:
4 ohm and 36 ohm (for
70.7V 138W/100V 276W).
Select the desired setting and
reinsert rubber plug. Note:
The grille-mounted tap switch
cover is keyed; be sure flat
edge of plug lines up with flat
edge of hole in grille.
2. Slip terminal weather
boot over signal wire. For
environmental applications,
put RTV silicone around
nipple and base when
installation is complete.
3. Conne sict gnal wire to
4-pi uro loc pln E b k ug. Tighten
unused termin ws. Useal scre
in de sit a neg vesi po ive nd ati
inputs for either voice rcoil o
d t buted sy e . is ri st ms For aid sy
c ning o idhai , use uts e positive
and negative n termi als.
9. Attach hanging cable to
the center hole in the
speaker hanging bracket.
11. Insert 4-pin Euroblock
plug into Euroblock jack on
rear of speaker. Connectors
are keyed for polarity.
12. Use zip or twist-lo ieck t s
to se urec safety cable & signal
wire to main hangi cabng les.
Ca leb cover available fo r
as het tic applications (SLT-10).
5. Thread hanging or safety
cable through SpeedClamp™
mechanisms as shown.
7. Thread cable end(s)
through SpeedClamp™
mechanisms as shown.
6. Attach the hanging cable
by securing it and safety
cable to structure as shown.
10. At ach t the safety cable to
one of the secondary holes in
the hanging bracket.
8. Adjust speaker hanging
height with SpeedClamp™
mechanism. Pull to tighten &
insert release key (small hex
wrench) into SpeedClamp ™
as shown to loosen or adjust.
SoundTube also provides optional surface-mount brackets for both the RS and HP lines of products.
Installation instructions for these accessories are included with specific accessory packaging.
4. When daisy chaining, wire
the outside terminals to the
inside terminals of the next
speaker. This step only applies
to tap settings using the
transformer and not when the
speaker is used on bypass.
RS1201i-SuperT™
RS1201i-SuperT
™
