SBPM JParapet Mount Bracket InstruconInstallaon s

Note: The mount should be installed on a flat and sturdy surface. The installation surface

must be capable of withstanding heavy winds and at least 3 times the total weight of the

camera being installed.

1.Start by marking off holes in which you want to position the mount.

2.Drill a hole in the base material with a hammer drill and a correctly sized carbide drill

bit for the anchor. See figure A

3.Using the proper diameter and use bit, drill holes for the expansion bolts. The depth of

the hole should accommodate the length of the bolt up to the shim.

4.Clean out the hole of all debris.

5.theSleeve with bolt and ensure the sleeve isInsert Expansion Anchor into the hole

flush with the surface. See figure B

6., insert flat washer, locking washerSet the mount base over the single expansion anchor

then tighten the nut of the expansion bolt. The anchor of the bolt will expand inside the

hole. See figure C and lock into place. Do this for all 6 expansion bolts.

7.Make the camera connections through the hollow arm and mount the camera to the

arm using the mounting collar and set screws.

8.Insert the arm to the base and use the included locking screws to lock it in place.

Box contents:

1 Parapet Mount and base with PTZ collar

1 PC x Hex Wrench for Setting Screws

6 Sets Mounting 63mm±0.5mm (Total Length) x bolts with expansion anchors

9 PCS SetScrewx s

Ø 6mm±0.2mm

①mounng holes for SPECO or Specic Metal Plate

②seng holes to x Metal Plate and Tube

Instrucons are subject and specifications to change without noce.
