Seite 1/74
Owner
'
s Manual
25 Watt VHF/FM
Marine Transceiver
SPECTRUM + GX2355S
A/B
H/L
PA/FOG
NAV
SCAN
MEM
CALL
SET
DISTRESS
P
U
L
L
O
P
E
N
16/9
SPECTRUM+
VOL/PWR
SQL
16/9
WX
Submersible
DSC distress call automatically broadcasts lat/long and vessel ID
∗
MARITEL DSC telephone capability
DSC position request function and NMEA data input/output
Noise canceling Clear Voice Speaker microphone with channel selector
20 W Loud Hailer with Bells & Whistles
Latitude/Longitude and SOG/COG display
∗
Channel name capability
Versatile user-programmable scanning and priority scan
NOAA Weather Alert
One-button access to Channel 16 and 9
Access all US, Canadian and International channels
Big, back-lit display and keys
∗
with GPS attached
TABLE OF CONTENTS
FCC RADIO LICENSE INFORMATION ...... 1
STATION LICENSE ..................................... 1
RADIO CALL SIGN ...................................... 1
CANADIAN SHIP STATION LICENSING .... 1
FCC NOTICE ................................................ 2
1 GENERAL INFORMATION ................. 3
1.1 INTRODUCTION ................................. 3
1.2
FCC/ INDUSTRY CANADA INFORMATION ..
3
2 ACCESSORIES .................................... 4
2.1 PACKING LIST .................................... 4
2.2 OPTIONS ............................................. 4
3 CONTROLS AND INDICATORS ......... 5
3.1 CONTROLS AND CONNECTIONS .... 5
4 INSTALLATION ................................. 10
4.1 LOCATION ......................................... 10
4.2 ELECTRICAL CONNECTIONS ......... 10
4.3 ACCESSORY CABLE ....................... 11
4.3.1 Cable pin number and signal ..... 11
4.4
CMB16 FLUSH MOUNT INSTALLATION ...
12
5 BASIC OPERATION .......................... 13
5.1 RECEPTION ...................................... 13
5.2 TRANSMISSION ................................ 13
5.3
TRANSMIT TIME - OUT TIMER (TOT) ...
14
5.4 SIMPLEX/DUPLEX CHANNEL USE ... 14
5.5 USA, CANADA, AND INTERNATIONAL
MODE ................................................ 14
5.6 NOAA WEATHER CHANNELS ......... 15
5.7 NOAA WEATHER ALERT ................. 15
5.8 MEMORY SCANNING (M-SCAN) ..... 16
5.9 PRIORITY SCANNING (P-SCAN) .... 16
5.10 CHANNEL A /B INSTANT CALL ....... 17
5.10.1 Storing new channel A/B ............ 17
5.10.2 Changing the stored channel A/B .. 17
5.10.3 Operating the channel A/B ........ 17
5.11.PA/FOG OPERATION ....................... 17
5.11.1 Operating the PA HAIL mode ..... 18
5.11.2 Operating the FOG HORN mode 18
5.12 NAVIGATION INDICATION ............... 19
5.13 VOICE SCRAMBLER ........................ 19
5.13.1 Operation with voice scrambler .. 19
5.14 RESETTING THE TRANSCEIVER’S
MICROPROCESSOR ........................ 20
6 DIGITAL SELECTIVE CALLING ....... 21
6.1 GENERAL .......................................... 21
6.1.1 Digital Selective Calling (DSC) ... 21
6.1.2 Maritime Mobile Service Identity
(MMSI) ........................................ 21
6.2 SENDING A DISTRESS CALL .......... 22
6.2.1 Sending a Distress Call
Automatically............................... 22
6.2.2 Sending a Distress Call and
Manually Inputting a Position ..... 23
6.3 SENDING A DISTRESS CALL WITH
NATURE OF DISTRESS ................... 24
6.4 SENDING AN INDIVIDUAL CALL ..... 25
6.5 SENDING A GROUP CALL ............... 26
6.6 SENDING AN ALL SHIPS CALL ....... 27
6.7 MARITEL DSC TELEPHONE CALL .... 28
6.7.1 Sending a Ship to Shore Call ..... 28
6.7.2 Receiving a Shore to Ship Call .. 29
6.7.3 Resend Telephone Call Signal ... 29
6.7.4 Resend Telephone Call When
Receive Busy Signal ................... 29
6.8 DSC STANDBY ................................. 30
6.9 CALL WAITING DIRECTORY ........... 30
6.9.1
Operation of Distress Call Waiting .
31
6.9.2
Operation of Individual Call Waiting ..
31
6.10 POSITION REQUEST ....................... 32
6.11 POSITION SEND ............................... 33
