Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: November 22, 2022

Product Diagram (4PCIE-PCIE-ENCLOSURE)

PCIe Expansion Chassis

PCIe 2.0 to 4 PCIe Slots Expansion Chassis - USB Type-C

Port/LED/

Connector

Function

1

PCIe Expansion

Slots

• Install up to Four PCIe cards

• PCIe version 2.0 p1-x1 slots

• 10 Gbps aggregate host bandwidth

• Full length cards supported

2

Mounting

Brackets

• (Optional) Allows for a permanent installation of the PCIe

Expansion Chassis to a at and stable surface

• at the and of the Mounting HolesFrontBackPCIe

Expansion ChassisMounting Brackets secure the

3On/O Switch

• Turns the or Expansion Chassis OnO

• The correct sequence to power the device:

• Power on: Power the OnPCIeExpansion Chassis

rst, then the Host Computer

• Power o: Power the rst, then OHost Computer

the PCIe Expansion Chassis

4DC Power Port

• Connect the to a PCIeExpansion ChassisPower Source

using the included Power Adapter

• Recommended 12 V and 3 A. Supports 12 to 24 V input

5

USB Type-C

Connector

• Used to connect the to a PCIeExpansion Chassis Host

Computer

• If the is disconnected during use, USB Type-C Cable

the must be restarted to reestablish the Host Computer

connection

• For a secure and correct cable connection, threaded

holes around the r allow to USB Type-C Connecto

Screw-lockUSB Type-C Cable the included

6

USB Type-C LED

Indicator

• Indicates if the included is on the USB Type-C-Cable

correct orientation. The cable is not reversible

• Solid Green = Correct orientation

7

Power LED

Indicator

• Indicates if the is turned or On/O SwitchOnO

• Solid Red = On

• O = O

8

Terminal Block

Connector

• Connect the to a PCIeExpansion ChassisDC Power

Source

• Recommended 12 V and 3 A. Supports 12 to 24 V input

9Metal Cover• Remove the to install the Metal CoverPCIe cards

3

7

4

1

6

5

8

9

2

*Product may vary from image
