Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: September 17, 2024
Product ID
8NM8-RACK-MOUNT-PDU
12NM8-RACK-MOUNT-PDU
16NM8-RACK-MOUNT-PDU
Front
Rear
Package Contents
• Metered PDU x 1
• Quick-Start Guide x 1
Requirements
• Available AC Power Source (NEMA 5-15R Outlet)
• Available 1U of EIA-310 Compliant Rack Space
• 4x Cage Nuts (If the 1U of Rack-Space Features Square Mounting Holes)
• 4x Cabinet Screws
For the latest drivers, manuals, product information, technical specications, and
declarations of conformance, please visit:
www.StarTech.com/8NM8-RACK-MOUNT-PDU
www.StarTech.com/12NM8-RACK-MOUNT-PDU
www.StarTech.com/16NM8-RACK-MOUNT-PDU
1U Rack-Mount Metered PDU with LCD Display & Surge Protection
ComponentFunction
1
LCD Display
(Orange Backlight)
• Displays real-time Volts, Amps, Watts, and
Power Factor
2
Protection Present
LED
• Solid Green: Surge Protection is active
• O: Surge Protection is o or damaged
3Outlets
• Connects to an AC Input on Downstream Device(s)
• NEMA 5-15R Connector
• 125V AC / 15A
4
Circuit Breaker
(With Switch Guard)
• Turns o All Power, in the event of a Power Surge
• 15A Tripping Point
• Push to Reset
5
Built-in 19in Mounting
Brackets (x2)
• Mounts the Metered PDU into 1U of Rack Space
• EIA-310 Compliant
6Built-in Power Cable
• Connect to an AC Power Source
• NEMA 5-15P Connector
• 125V AC / 15A
1
3
6
5
5
3
4
2
*12NM8-RACK-MOUNT-PDU shown
