Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support

Manual Revision: June 20, 2022 4:53 PM

Product Diagram (ADJ-TABLET-STAND-W)

Front View

ComponentFunction

1Clamp

• For up to 12.9 in . on either side TabletsHolders

support the in placeTablet

• Width range from 5 to 8 in (12.8 to 22.4 cm)

• Maximum thickness 0.4 in (1.1 cm)

• Allow to rotate 360°, up and down, and side to side

2

Rotation Adjustment

Knob

• Varies the resistance of the or xes it RotationClamp

on a specic position

3

Clamp Tilt

Adjustment Screw

• Adjust the of the of the ResistanceTilt AngleClamp

4

Support Arm Tilt

Adjustment Screws

• Adjust the of the of the ResistanceTilt AngleUpper

and sections of the LowerSupport Arm

5Support Arm

• Supports the weight of the and provides Tablet

HeightTilt Adjustment and

6Mounting Holes• Allow to x the on a permanent locationTablet Stand

7Base

• Supports the in place. at the AssemblyFoam Pads

bottom protect the desk or table surface

Universal Tablet Desk Stand - White

Package Contents

• Tablet Stand x 1

• 4.2x19 mm Wood Screws x 4

• 3 mm Hex Key x 1

• 5 mm Hex Key x 1

• Quick-Start Guide x 1

Requirements

For the latest manuals, product information, technical specications, and declarations of

conformance, please visit: www.startech.com/ADJ-TABLET-STAND-W

• Phillips head screwdriver

Operation

WARNINGS!

Do not exceed the weight capacity of this product. Overloading this product might

result in injury or property damage. This product can support the following weight: up

to 2.2 lb (1 kg).

When adjusting the tilt or height of this product, ensure that the mounted equipment

is properly secured and the weight is fully supported. Failure to follow these guidelines

may result in property damage and/or personal injury.

When not xed to a surface, always use two hands to ensure a controlled movement

when adjusting the height or tilt angle of this product to prevent tipping it over.

Is recommended to remove any protective case from the Tablet to t properly on the

Holders.

1. Slide the outwards to make enough room to mount the HoldersTabletVertically

on the If the is enough, it can be mounted too. Clamp.TabletSmallHorizontally

Figure 1

7

6

1

5

2

4

4

3

*Product may vary from image
