Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support

Manual Revision: December 17, 2021 12:22 PM

Product Diagram (TABLET-VESA-ADAPTER)

Tablet Mount Adapter – 7.9-12.5” – VESA Compatible (75x75/100x100)

Component Function

1Clamp • Attach the to the Tablet Tablet Mount Adapter

2Body • Frame of the Tablet Mount Adapter

3VESA Bracket

• Attach the to a compatible Tablet Mount Adapter

VESA Mount

4Lock

• Prevents opening the to Tablet Mount Adapter

remove the tablet

5Weighted Plate

• Adds additional weight for that have Monitor Mounts

a minimal weight capacity

Package Contents

• Tablet Holder x 1 (0.47 lb / 215 g)

• Weighted Plate x 1 (0.77 lb / 350 g)

• Keys x 2

• Star Bit Tool x 1

• M4x8 Tamper Resistant Screws x 4

• M4x10Tamper Resistant Screws x 4

• Washers x 4

• Quick-start Guide x 1

Requirements

For the latest manuals, product information, technical specications, and declarations of

conformance, please visit: www.startech.com/TABLET-VESA-ADAPTER

• Monitor Mount with a VESA 75x75 or 100x100 patterns

• A tablet with a display size from 7.9 in to 12.5 in diagonally

Installation

WARNINGS!

Do not exceed the weight capacity of this product. Overloading this product might

result in injury or property damage. This product can support the following weight: up

to .4.4 lbs (2 kg)

Ensure the has been properly secured before use and/or adjustment.Tablet

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of

third-party companies not related in any way to StarTech.com. Where they occur these references are for illustrative

purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. StarTech.com hereby acknowledges that

all trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual

and related documents are the property of their respective holders..

Warranty Information

This product is backed by a 5-year warranty.

For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or

agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of

prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price

paid for the product. Some states do not allow the exclusion or limitation of incidental or consequential damages. If such

laws apply, the limitations or exclusions contained in this statement may not apply to you.

FR: startech.com/fr

DE: startech.com/de

ES: startech.com/es

NL: startech.com/nl

IT: startech.com/it

JP: startech.com/jp

StarTech.com Ltd.

45 Artisans Crescent

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Road

Brackmills,

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

4490 South Hamilton

Road

Groveport, Ohio

43125

U.S.A.

StarTech.com Ltd.

Siriusdreef 17-27

2132 WT Hoofddorp

The Netherlands

Attach the Tablet Mount Adapter to a Monitor Mount

The VESA Bracket is compatible with VESA patterns 75x75 and 100x100 mm.

Certain Spring-Assisted Monitor Mounts require a minimum weight to

counterbalance the spring mechanism, if this is being used with one of those

mounts, follow the appropriate step below.

Non-Spring Assisted Monitor Mounts

1. Place the (x 4) on the .Washers M4x8 Tamper Resistant Screws

2. Align the holes located on the , with the holes, located on the VESA Bracket

Monitor Mount.

3. Insert the (x 4) through the and M4x8 Tamper Resistant Screws Monitor Mount

into the and , tighten using the .VESA Bracket Star Bit Tool

Spring-Assisted Monitor Mounts

1. Place the (x 4) on the .Washers M4x8 Tamper Resistant Screws

2. Gently place the over the and ensure the holes Weighted Plate VESA Bracket

located on the , are aligned with the holes located on the Weighted Plate VESA

Bracket.

3. Align the holes located on the and , with the VESA Bracket Weighted Plate

holes, located on the .Monitor Mount

4. Insert the (x 4) through the M4x10 Tamper Resistant Screws Monitor Mount

and into the and , tighten using the .Weighted Plate VESA Bracket Star Bit Tool

Attach a Tablet to the Tablet Mount Adapter

1. Slide the outwards to accommodate the diagonally. Clamp Tablet

2. Insert the opposite corners of the in the . Tablet Clamp

3. Secure the , using the and .Clamp Lock Key
