Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: August 28, 2019 8:48 AM

Product Diagram (DK30CHHPD/DK30CHHPDUK/

DK30CHHPDEU/DK30CHHPDAU)

Front

ComponentFunction

1USB-A Port

• Used to charge a connected .USB Device

• Used to connect to the USB DevicesDocking

Station (ash drive, etc.).

• BC 1.2 Compliant.

• 7.5W of power output.

• Charges with or without a connection to the

Host Computer.

2USB-C Port

• Used to charge a connected .USB Device

• B.C. 1.2 compliant.

• 7.5 W of power output.

• Charges with or without a connection to the

Host Computer.

33.5 mm Audio Port

• Used to connect an to the Audio Device

Docking Station (headset, microphone, etc.).

4Mounting Holes (x 4)

• Used to mount the to a desk Docking Station

or wall.

Note: Located on the bottom of the Docking

Station.

5Power Button• Used to turn the On/O.Docking Station

6 Lock Slot

• Used to secure the to a Docking Station

secure stationary object.

Note: Located on the side of the Docking

Station.

USB-C Dual Video 1080p Monitor, USB 3.1 Gen 1 Dock

Rear

ComponentFunction

7Power Connector

• Used to power the by Docking Station

connecting the to Universal Power Adapter

the .Docking Station

8USB-C Host Port

• Used to connect the to the Host Computer

Docking Station.

• Used to charge the connected .Host Computer

• Power Delivery 3.0.

• 60W of power output.

9

HDMI Video 1 and 2

Ports (x 2)

• Used to connect two to HDMI Display Devices

the .Docking Station

• 1920x1200 @ 60 Hz.Maximum Resolution:

10RJ-45 Port

• Used to connect a to the Network Device

Docking Station.

11USB-A Ports (x 2)

• Used to connect to the USB DevicesDocking

Station (mouse, keyboard, etc.).

Requirements

For the latest requirements, please visit www.startech.com/DK30CHHPD

Powering the Docking Station

1. Connect the to the on the Universal Power AdapterPower ConnectorDocking

Station.

2. Connect theto theand to an Power Cord Universal Power Adapter AC Electrical

Outlet.

1

2

3

4

5

6

7

891011
