Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: June 18, 2020

Product Diagram (IESC1G80UP)

Front View

Side View

ComponentFunction

1PoE Ports

• Connect any to provide an Network DeviceEthernet

ConnectionNetwork Devices to up to 8

• Provide a to 8 PoE ConnectionDevices

• Maximum PoE power budget is 30W per port up to a

total overall power budget of 200W

2ERR LED Indicator

• Color - Amber

• On - Either or is connectedPW1PW2

• O - Both and are connectedPW1PW2

8 Port Unmanaged Industrial-Grade Switch 10/100/1000 Mbps

3PW2 LED Indicator

• Color - Green

• On - when and are connectedPW2+PW2-

• O- when and are not connected PW2+PW2-

4PW1 LED Indicator

• Color - Green

• On - when and are connectedPW1+PW1-

• O- when and are not connectedPW1+PW1-

5PoE LED Indicators

• Indicates the link and status PoEPowered Device (PD)

of each PoE Port

LNK(Green)

• On - Network connection detected

• O - Network connection not detected

PoE (Amber)

• On - is detectedPoE

• O - is not detectedPoE

6

Terminal Block Power

Input Port

• Provides power to the PoE Ports

• Supported power input voltage range is 48-56V

7Grounding Screw

• Attach a to protect Grounding WireNetwork

Equipment

Requirements

For the latest requirements, please visit .www.startech.com/IESC1G80UP

• DC Power Supply x 1 (maximum of two)

• PoE Powered Device x (up to) 8

• RJ45 Terminated UTP/STP Cat 5e (or better) Network Cable (sold separately) x 8

• Earth Ground Connection x 1

• Grounding Wire x 1

• (Optional - for power) Flat Head Screwdriver x 1

• (Optional) #2 Phillips Head Screwdriver x 1

• (Optional) Screws for Wall Mounting x 2

Installation

Grounding the Switch

1. Using the loosen the on the . Phillips Head ScrewdriverGrounding Screw Switch

2. Attach the to the . Grounding WireGrounding Screw

67

2

3

4

5

1
