Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: July 18, 2019 11:29 AM

Product Diagram (ITB20D3250)

Component Function

1Power Connector (side) • Used to power the .Adapter

2LED Indicator

• Indicates that the is powered Solid: Adapter

On.

• Indicates that the is not receiving O: Adapter

power.

3Terminal Block Wires

• Used to connect and power a .Device

• = PositiveRed Wire

• = NegativeBlack Wire

• = 20VOutput

• = 3.25A 65WCurrent

Requirements

For the latest requirements, please visit www.startech.com/ITB20D3250

• (Optional) Small Flat Head Screwdriver x 1

• Device with a Two or Three Conductor Terminal Block Connector x 1

Using the Two Conductor Terminal Block Connector

1. Remove the from the , you want Two Conductor Terminal Block Connector Device

to power.

2. Plug the on the into the Two Conductor Terminal Block Connector Adapter

Terminal Connector Device on the .

Note: Ensure the polarity of the input power is correctly matched with the Terminal

Block Pins Device’s to ensure proper functionality. Refer to the vendor manual for

further information on properly wiring the .Device

Universal 65W DC Power Adapter | 20V 3.25A | Industrial

Two Conductor Terminal Block Connector

Using the Three Conductor Terminal Block Connector

1. Using a small screwdriver (Flat Head), loosen the screws on the Two Conductor

Terminal Block Connector Terminal Block Wiresand carefully remove the from

the . Two Conductor Terminal Block Connector

2. Using a small screwdriver, loosen the screws on the Three Conductor Terminal

Block Connector Terminal Block Wires (included) and carefully insert the into the

Three Conductor Terminal Block Connector (Red Wire = Positive and Black Wire =

Negative).

Note: Ensure the polarity of the input power is correctly matched with the Terminal

Block Pins Device’s to ensure proper functionality. Refer to the vendor manual for

further information on properly wiring the .Device

3. Tighten the screws on the , to secure Three Conductor Terminal Block Connector

the into the .Terminal Block Wires Three Conductor Terminal Block Connector

Three Conductor Terminal Block Connector

4. Plug the on the into the Three Conductor Terminal Block Connector Adapter

Terminal Connector Device on the .

Powering the Adapter

• Connect the to the on the and to an Power Cord Power Connector Adapter AC

Electrical Outlet.

Produktspezifikationen

Marke:	StarTech.com
Kategorie:	USB-Hub
Modell:	ITB20D3250
Breite:	53 mm
Tiefe:	115 mm
Gewicht:	291 g
Mitgelieferte Kabel:	AC
Produktfarbe:	Schwarz
Höhe:	35 mm
Zweck:	Universal
Stecker:	Anschlussklemme
Betriebstemperatur:	0 - 40 °C
Relative Luftfeuchtigkeit in Betrieb:	20 - 80 %
Verpackungsbreite:	242 mm
Verpackungstiefe:	166 mm
Verpackungshöhe:	55 mm
Paketgewicht:	843 g
Zertifizierung:	REACH, CE, FCC, UL, PSE
Warentarifnummer (HS):	85044095
Menge pro Packung:	1 Stück(e)
Temperaturbereich bei Lagerung:	-20 - 80 °C
Netzteiltyp:	Drinnen
Ausgangsstrom:	3.25 A
Ausgangsspannung:	20 V
Schnellinstallationsanleitung:	Ja
Ausgangsleistung:	65 W
Eingangsspannung:	110 - 240 V
Nachhaltigkeitszertifikate:	RoHS
Eingangsstrom:	1.4 A
Markenkompatibilität:	StarTech.com
Steckertypen enthalten:	ANZ, EU, JP, NA, UK
