Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: June 3, 2022 4:17 PM

Product ID

5G4AINDNP-USB-A-HUB

4-Port Industrial USB Hub - 15kV/8kV Air/Contact ESD Protection - Mountable

ComponentFunction

1

USB Host Port

(Screw Locking, USB-B)

• Connect to a USB-A Port on a Host Computer

• USB 3.2 Gen 1 (5 Gbps)

2

DC 2-Wire Terminal Block Power

Input

• Connect a +5~24 V DC Power Source

• 30W or higher recommended for maximum

power performance

3

DC Power Input

• Connect a +5~24 V DC Power Source

• 30W or higher recommended for maximum

power performance

4

4x USB Data/Charge Ports & Port

Connectivity LEDs

(Screw Locking, USB-A)

• Connect USB Peripherals

• USB 3.2 Gen 1 (5 Gbps)

• BC 1.2 for up to 5 V/1.5 A (7.5 W) Charging

• LED illuminates green when a device is

actively connected to the host computer

5

Mounting Brackets

• Wall mount the USB Hub

• Mount the USB Hub to the side/underside of

a Desk

Product Diagram

123

5

4

Package Contents

• USB Hub x 1

• 6 ft [1.8 m] USB-A to USB-B Cable x 1

• Terminal Block Connector (Attached)

• DIN Rail Mounting Brackets (with Mounting Screws) x 2

• Quick-Start Guide x 1

Requirements

• Computer

• USB-A Port

• 5-24V DC Power Source

For the latest drivers, manuals, product information, technical specications, and

declarations of conformance, please visit:

www.StarTech.com/5G4AINDNP-USB-A-HUB

Installation

Notes:

• Connect the after all the other installation steps have been completed. Power Source

• There are two ways to power the . USBHub

Using an external or a . DC Power Adapter Terminal Block Power Source

Voltage (+5 - 24 V DC).

Connect the USB Ports

1. Connect up to four USB peripherals to the Screw Locking USB Data/Charge

Ports,USB Hub located on the .

2. Use theUSB-A to USB-B CablesComputer , to connect a USB port on each to the

USB Host PortUSB Hub, located on the .

• The will automatically detect the device and install the required Computer

drivers for the . USB Hub
