Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Product Diagram (ST7C51224EU)

Port/LEDFunction

1USB-A Ports (7)

• Used to charge multiple .Devices

Note: 2A Devices can be charged using a

USB-A (1A) Port1A Devices, and can be

charged in the however, the USB-A (2A) Port,

charging time will be aected.

2Power LED

• Solid red indicates that the is Charging Hub

receiving power.

3 Power Button• Used to turn the On or O.Charging Hub

4DC IN 12V• Used to power the .Charging Hub

7 Port USB Dedicated Charging Station |5 x 1A | 2 x 2A

3

Requirements

For the latest requirements, please visit .www.startech.com/ST7C51224EU

Installation

Notes: The features a chipset that can detect the required charging Charging Hub

mode of a device, and switch to the proper mode for full-speed charging (e.g. If an

Apple device is connected, it will automatically charge to Apple charging mode

specications).

When charging multiple devices, the may become warm to the touch, Charging Hub

this is normal and will not harm the connected .Device(s)

1. Connect the to an and to the Power AdapterAC Electrical Outlet DC IN 12V Port

on the. Charging Hub

2. Press the to turn the On. Wait until the is Power ButtonCharging HubPower LED

solid before connecting any devices for charging.

3. Connect your device(s) to the corresponding on the USB-A Port (1A or 2A)

Charging HubDevice(s), according to the charging requirements of the connected :

• 1A:

• Voltage at the common collector (VCC) = 5V

• Ground (GND) = 5V

• D+ = 2.0V

• D- = 2.7V

• 2A:

• Voltage at the common collector (VCC) = 5V

• Ground (GND) = 5V

• D+ = 2.7V

• D- = 2.0V

Installing the Mounting Brackets (Optional)

1. Align the on the with the four Mounting HolesMounting BracketMounting Holes

on the back of the .Charging Hub

2. Insert the (x4) through the and into the Bracket ScrewsMounting Bracket

Mounting Holes Charging Hubon the back of the.

3. Tighten the using a , be careful not to Mounting ScrewsPhillips Head Screwdriver

over-tighten.

4

2

1
