Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support

Manual Revision: May 9, 2024

Product Diagram

OR41GI-NETWORK-CARD

Port/LED/ConnectorFunction

1Pull Tab

• Pull to remove the from the Server Network Card

OCP NIC 3.0 Slot

2RJ45 Port x 4

• Connect a to theNetwork Cable Server Network

Card

• Supports 1 Gbps, 100 Mbps, and 10 Mbps

3LED Indicators

• LeftLED Indicator Link Speedis

• Solid Green: 1 Gbps

• Solid Amber: 10/100 Mbps

• RightLED Indicator Link Statusis

• Solid Green: Active link

• Flashing Green: Activity

4

4C+ Connector

(OCP NIC 3.0)

• Insert into an on the OCP NIC 3.0 SlotHost Server

5Locking Screw• Secure the card to the Host Server Case

4-Port RJ45 Gigabit OCP 3.0 Server Network Card

Package Contents

• OCP NIC 3.0 Network Card x 1

• Quick-Start Guide x 1

Requirements

For the latest requirements, please visit www.startech.com/OR41GI-NETWORK-CARD

• Host server with an available OCP NIC 3.0 slot

Installation

Install the Server Network Card

WARNING!

Static Electricity can severely damage. Ensure that you are adequately Network Cards

groundedHost Server CaseServer Network Card before you open your or touch the .

You should wear an oruseanwhen installing any Anti-Static Strap Anti-Static Mat

computer component. If an isn’t available, discharge any built-up Anti-Static Strap

static electricity by touching a large for several seconds. Only Grounded Metal Surface

handle the by its edges and do not touch the gold connectors.Server Network Card

1. Turn o the and any that are connected to it (e.g. Host Server Peripheral Devices

printers, external hard drives, etc.).

2. Unplug the from the back of the , and disconnect any Power Cable Host Server

Peripheral Devices that are connected.

3. Remove the from the . Consult the documentation that came with Cover Server Case

the for details about doing this safely.Host Server

4. Locate an open and remove the corresponding OCP NIC 3.0 Slot Slot Cover Plate

from the back of the .Host Server

5. Gently insert the into the. Turn the Server Network Card OCP NIC 3.0 SlotLocking

Screw Server Network CardServer Case/Chassisto attach the to the back of the .

6. Return the onto the .CoverHost Server

7. Connect one or more to the on the Network Cable/sRJ45 Ports Server Network

Card.

8. Reconnect all of the disconnected in .Peripheral DevicesStep 2

9. Reconnect the to the back of the .Power CableHost Server

10. Turn on the and .Host ServerPeripheral Devices

3

4

2

5

1

*Product may vary from image
