Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support

Manual Revision: June 1, 2023

Product Diagram

P041GI-NETWORK-CARD

Port/LED/ConnectorFunction

1Bracket

• Secures the card to the Host Computer Case

• The comes pre-installedFull Prole Bracket

2Open SFP Slot x 4

• Add a MSA-Compliant SFP Transceiver Module

• Supports or FiberEthernet1 Gbps SFPs

3LED Indicators

• LeftLED Indicator Link Speedis

• Solid Green: 1 Gbps

• RightLED Indicator Link Statusis

• Solid Green: Active link

• Flashing Green: Activity

4PCIe 2.0 p1-x2 Connector• Insert into a on the PCI Express SlotHost Computer

Package Contents

• Open SFP Network Card x 1

• Quick-Start Guide x 1

4-Port Open SFP Gigabit Network Card

Requirements

For the latest requirements, please visit www.startech.com/P041GI-NETWORK-CARD

• Host computer with an available PCI Express 2.0 or greater slot (x2, x4, x8, or x16)

Installation

Install the PCI Express Card

WARNING!

Static Electricity PCI Express Cardscan severely damage. Ensure that you are

adequately before you open your or touch the GroundedHost Computer CasePCI

Express CardAnti-Static Strap Anti-Static Mat . You should wear an oruseanwhen

installing any Host Computer component. If an isn’t available, Anti-Static Strap

discharge any built-up static electricity by touching a large Grounded Metal Surface

for several seconds. Only handle the by its edges and don’t touch PCI Express Card

the gold connectors.

1. Turn o the and any that are connected to it Host Computer Peripheral Devices

(e.g. printers, external hard drives, etc.).

2. Unplug the from the back of the .Power Cable Host Computer

3. Disconnect any that are connected to the .Peripheral Devices Host Computer

4. Remove the from the . Consult the documentation that Cover Host Computer Case

came with the for details about doing this safely.Host Computer

5. Locate an open and remove the corresponding PCI Express SlotSlot Cover Plate

from the back of the . Host Computer Case

Note: Consult the documentation that came with the for details Host Computer

about doing this safely. This card works in PCI Express x2, x4, x8, or x16 Slots.

6. Gently insert the into the open and fasten the PCI Express CardPCI Express Slot

BracketHost Computer Case to the back of the .

7. Return the onto the .CoverHost Computer Case

8. Insert a compatible 1G SFP Transceiver ModuleSFP Slot PCI , into the onto the

Express Card.

9. Reconnect the to the back of the .Power CableHost Computer

10. Reconnect all of the disconnected in .Peripheral DevicesStep 3

11. Connect a or depending on the Fiber Ethernet Network Cable SFP Transceiver

Module Network Deviceused. Connect the other end of the cable to a .

3

*Product may vary from image

1

4

2
