Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: October 6, 2023 11:25 AM

Product ID

PAX2235-WIFI-6E-CARD

PCIe Wi-Fi 6/6E Network Adapter Card - 802.11ax

ComponentFunction

1LED Indicator

• Solid Green: PCIe Wi-Fi Card is installed and

receiving power

2Full Prole Bracket

• Secure the to the PCIe Wi-Fi CardComputer

Case

3Antenna Connectors

• Connect the from the Antenna CablesMagnetic

Antenna Stand

4Bluetooth USB 2.0 Header

• Connect to a on the USB 2.0 HeaderComputer’s

MotherboardBluetooth , using the included

Cable

5PCIe p1-x1 Connector

• Connect the to ain a PCIe Wi-Fi Card PCIe Slot

Computer

6Magnetic Antenna StandProvides adjustable placement of the • Antenna

Requirements

For the latest drivers/software, technical specications, and declarations of

conformance, please visit: www.StarTech.com/PAX2235-WIFI-6E-CARD

Package Contents

• PCIe Wi-Fi Card x 1

• Magnetic Antenna Stand x 1

• Bluetooth Cable x 1

• Low-Prole Bracket x 1

• Quick-Start Guide x 1

Installation

Warning: PCIe Cards can be damaged by static electricity. Ensure that the Installer

is properly grounded before they open the or touch the Computer CasePCIe Wi-Fi

Card Anti-Static Strap. The Installer should wear an when installing any computer

component. If an is not available, discharge any built-up static Anti-Static Strap

electricity by touching a large for several seconds. Only Grounded Metal Surface

handle the by its edges and do not touch the gold connectors. PCIe Wi-Fi Card

(Optional) Installing the Low Prole Bracket

Note: By default the is attached to the Full Prole BracketPCIe Wi-Fi Card.

Depending on the system conguration the may need to be Full Prole Bracket

removed and replaced with the (included).Low Prole Bracket

1. Ensure the are disconnected from the .Antenna CablesPCIe Wi-Fi Card

2. Using a , remove the two securing Small Phillips Head ScrewdriverBracket Screws

the to the. Set the aside as Full Prole Bracket PCIe Wi-Fi CardBracket Screws

they will be used to attach the .Low Prole Bracket

2

1

3

3

5

6

4
