Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: February 22, 2023 1:29 PM

Product ID

PEX4SFF8639U3

Component Function

1LED Jumper Pins

• Connect to the LED Lights U.3 to PCIe p1-x4

Adapter Drive to show power/activity

• LED Lights not included

U.3 (SFF-TA-1001) Drive

Connector

• Connect a to U.3 (SFF-TA-1001) Storage Device

the U.3 to PCIe p1-x4 Adapter

3Drive Mounting Holes

• Secure the to the U.3 Storage Device U.3 to PCIe

x4 Adapter

4PCIe p1-x4 Connector

• Connect the to theU.3 to PCIe p1-x4 Adapter PCIe

Slot Computerin a

U.3 (SFF-TA-1001) to PCIe 4.0 p1-x4 Host Adapter for 2.5” U.3 NVMe SSDs

Requirements

For the latest drivers/software, technical specications, and declarations of

conformance, please visit: www.StarTech.com/PEX4SFF8639U3

Package Contents

• U.3 to PCIe p1-x4 Adapter x 1

• Drive Mounting Screws x 4

• Quick-Start Guide x 1

Installation

Connect an SSD to the Drive Adapter

Warning! Drives should be handled carefully, especially when being transported.

If not handled with care, lost or corrupted data may be experienced. Ensure that the

Installer Computer Case U.3 is properly grounded before opening the or touching the

to PCIe p1-x4 Adapter Installer . The should wear an when installing Anti-Static Strap

any computer component. If an is not available, discharge any Anti-Static Strap

built-up static electricity by touching a large for several Grounded Metal Surface

seconds. Only handle the U.3 to PCIe p1-x4 Adapter by its edges and do not touch the

gold connectors.

1. Carefully slide the into the and connect it to theSSD U.3 to PCIe p1-x4 Adapter U.3

(SFF-TA-1001) Connector on the card.

2. Turn over the .U.3 to PCIe p1-x4 Adapter

3. Use a and insert the four through Phillips Screwdriver Drive Mounting Screws

the on the and into the .Drive Mounting Holes U.3 to PCIe p1-x4 Adapter SSD

4. Tighten the to secure the drive to the .Screws U.3 to PCIe p1-x4 Adapter

Installing the Drive Adapter

1. Turn o the and any connected or (such as Computer Devices Peripherals

printers and external storage).

2. Unplug the from the back of the .Power Cable Computer

3. Disconnect any connected to the .Peripheral Devices Computer

4. Open the , referring to the documentation that came with the Computer Case

computer system for guidance.

1 2 3

Produktspezifikationen

Marke:	StarTech.com
Kategorie:	Regeln
Modell:	PEX4SFF8639U3
Breite:	90 mm
Tiefe:	154 mm
Gewicht:	62 g
Produktfarbe:	Rot
Höhe:	1.5 mm
Betriebstemperatur:	0 - 60 °C
Relative Luftfeuchtigkeit in Betrieb:	20 - 80 %
Verpackungsbreite:	215 mm
Verpackungstiefe:	155 mm
Verpackungshöhe:	30 mm
Paketgewicht:	130 g
Plug & Play:	Ja
Eingebaut:	Ja
LED-Anzeigen:	Activity, Power
Temperaturbereich bei Lagerung:	-40 - 80 °C
Anzahl Produkte pro Versandkarton:	60 Stück(e)
Länge des Versandkartons:	340 mm
Breite des Versandkartons:	460 mm
Höhe des Versandkartons:	490 mm
Mittlere Betriebsdauer zwischen Ausfällen (MTBF):	21693912 h
Schnellinstallationsanleitung:	Ja
Hostschnittstelle:	PCIe
Schrauben enthalten:	Ja
Hot-Swap:	Nein
Ausgangsschnittstelle:	U.3
Unterstütze Datenträgerhöhe:	5, 7,9.5, 12.5, 15 mm
