Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: September 29, 2023

Product ID

2S232422485-PC-CARD

PS74ADF-SERIAL-CARD

Port/LED/

Connector

Function

1Bracket

• Secures the card to the Host Computer Case

• Thecomes pre-installed Full Prole Bracket

• Theis included Low Prole Bracket

2Activity LEDs

• Data Receive LED: GreenFlash to show activity

• Data Transmit LED: YellowFlash to show activity

3DB9 Serial Ports• Connect Serial Peripheral Devices

4

Serial Mode

Switch

• Change thebetween, , DB9 Serial Ports RS-232RS-422

or RS-485

PCIe p1-x1 RS232/422/485 Serial Card - Low-Prole Brackets Included

5

J1/J2/J3/J4

Jumper

• Optional: Used to change the of Voltage Output DB9

Pin 9

• RI DB9 Pin 9disables power on . This is the default

setting.

• 12VSATA Power Connector draws power from the

(12VOutputs )

• 5V SATA Power Connector draws power from the

(5VOutputs)

6

PCIe p1-x1

Connector

• Insert into a on thePCI Express Slot Host Computer

7

SATA Power

Connector

• Optional: Connect an available SATA Power Connector

from the to provide power over Host Power Supply

DB9 Pin 9

Package Contents

2S232422485-PC-CARD:

• Serial Card x 1

• Low-Prole Bracket x 2

• Ribbon Cable x 1

• Quick-Start Guide x 1

Requirements

For the latest requirements, please visit: www.StarTech.com/2S232422485-PC-CARD

• Computer with an available PCI Express Slot (x1, x4, x8, or x16)

Installation

DIP Switch Settings

To change the between , , and , use the DB9 Serial Ports RS-232RS-422RS-485

respective located on the . enables/Serial Mode SwitchSerial CardDip Switch 3

disables a , used for impedance matching between the 120 Ω Termination Resistor

Tx+/Tx- and Rx+/Rx- (RS-422/RS-485 4-wire) and D+/D- (RS-485 2-wire) lines. The

purpose is to prevent reections on the line that may cause signal errors.

RS-232

RS-485 (Half-Duplex)

RS-422/485 (Full-Duplex)

1

3

3

2

2

6

4

4

5

5

7

*2S232422485-PC-CARD shown above

PS74ADF-SERIAL-CARD:

• Serial Card x 1

• Low-Prole Bracket x 4

• Ribbon Cable x 3

• Quick-Start Guide x 1
