Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: October 4, 2023

Product ID

2P1FFC-USB-SERIAL

ComponentFunction

1Serial Port DB9• Connect to a Serial Peripheral Device

2DB9 Nuts

• Used to secure the to the Serial DB9 Port Serial

Peripheral Device

• The included can be installed for DB9 Screws

compatibility with or Serial Peripheral DevicesCables

3LED Indicators

• Data Receive LED: Green Flashes to indicate activity

• Data Transmit LED: Yellow Flashesto indicate activity

• USB LED: BlueSolid to indicate driver has been

installed, and USB connection enumerated

4USB Type A Port

• Connect the to an available USB to Serial Adapter

USB-A Port

1ft (30cm) FTDI USB-A to 2-Port RS232 DB9 Serial Adapter Cable - M/M

Pinout Diagram

Package Contents

• 2-Port USB to Serial Adapter x 1

• Mounting Bracket x 1

• DB9 Screws x 4

• Quick-Start Guide x 1

Requirements

• USB Type-A Enabled Computer x 1

For the latest drivers/software, product information, technical specications, and

declarations of conformance, please visit: www.StarTech.com/2P1FFC-USB-SERIAL

Installation

(Optional) Mount the USB Serial Adapter

Note: Before mounting the make sure that the surface you are USB Serial Adapter

mounting to is strong enough to support the weight of the .USB Serial Adapter

1. Determine the and placement for the .Mounting Surface USB Serial Adapter

2. Mount the included to the desired using the Mounting Bracket Mounting Surface

appropriate (e.g., wood screws) through the two Mounting HardwareMounting

Bracket Holes.

Note: The Mounting Bracket is designed to t M4 Flat Head Screws

3. Press the rmly into the until it clicks into USB Serial Adapter Mounting Bracket

place.

4

3

1

PinRS-232

1DCD

2RXD

3TXD

4DTR

5GND

6DSR

7RTS

8CTS

9RI

2

2

54321

9876

1

3
