Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: September 5, 2024

Product ID

PS4C3IA3-USB-C-CARD

ComponentFunction

1Full-Prole Bracket• Secure the to the PCIe USB CardComputer Case

2USB-C Ports x 4• Connect a USB-C 10Gbps Peripheral Device

3USB-A Port• Connect a USB-A 10Gbps Peripheral Device

4SATA Power Connector

• Connect from theSATA Power Host Computer’s

Power Supply

5PCI Express p1-x4 Connector

• Connect the to ain a PCIe USB Card PCIe Slot

Computer

Product Information

For the latest product information, technical specications, and declarations of

conformance, please visit: www.StarTech.com/PS4C3IA3-USB-C-CARD

5-Port USB 3.2 Gen 2 10Gbps Combo Card - 4x USB-C, 1x USB-A - PCI-Express

Package Contents

• PCIe USB Card x 1

• Full-Prole Bracket (Installed) x 1

• Low-Prole Bracket x 1

• Quick-Start Guide x 1

Installation

(Optional) Installing the Low Prole Bracket

Note: By default the is installed on the Full-Prole BracketPCIe USB Card.

Depending on the system conguration the may need to be Full-Prole Bracket

removed and replaced with the (included).Low-Prole Bracket

1. Using a , remove the two securing Small Phillips Head ScrewdriverBracket Screws

the to the. Set the aside as they Full-Prole Bracket PCIe USB CardBracket Screws

will be used to attach the .Low-Prole Bracket

2. Align the on the with the on the Screw Holes PCIe USB CardScrew Holes

Low-Prole BracketScrew ensuring the PCIe USB Card is sitting on-top of the

HolesLow-Prole Bracket on the .

3. Insert the through the and into the on Bracket ScrewsPCIe USB Card Screw Holes

the .Low-Prole Bracket

4. Using the , tighten the , being Small Phillips Head ScrewdriverBracket Screws

careful not to over-tighten them.

Install the PCIe USB Card

1. Turn o the and disconnect the and any ComputerPower CablePeripheral Devices

that are connected (e.g. printers, external hard drives, etc.).

2. Remove the from the .CoverComputer Case

Note: Consult the documentation that came with the Computer for details about how

to do this safely.

3. Locate an open and remove the corresponding PCIe 3.0 x4, x8, or x16 SlotMetal

Cover PlateComputer CaseMetal from the rear of the . In most instances, the

Cover PlateComputer CasePhillips is attached to the rear of the with a single

Head ScrewPhillips Head Screw. Save this for the next step.

4. Gently insert the into the open and PCIe USB Card PCIe 3.0 x4, x8, or x16 Slot

fasten the to the rear of the , using the BracketComputer CasePhillips Head Screw

from .Step 3

5. (Optional) Connect from the to the SATA PowerHost Computer’s Power Supply

SATA Power ConnectorPCIe USB Card, located on the rear of the .

Note: Connecting SATA power to this card is optional but recommended to ensure

optimal performance and that the card and all connected devices receive sucient

power.

5

1

4

3

2
