Seite 1/2

Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: July 24, 2019 3:57 PM

Product Diagram (SSPMSVESA)

Component Function

VESA Mounting

Bracket

• Used to mount a StarTech.com Docking

Station Hub Monitor or to the back of a .

2VESA Mounting Holes

• Used to mount the to the back of a Adapter

Monitor Monitor’s VESA Mounting , using the

Pattern.

Note: VESA mounting sizes are 75x75 and

100x100.

3Mounting Holes

• Used to mount a StarTech.com Docking

Station Hub Adapter or to the .

Requirements

For the latest requirements, please visit www.startech.com/SSPMSVESA

If you are using a that covers the on the back of Monitor Stand VESA Mounting Holes

the , a VESA compatible monitor mount will be require to use the .Monitor Adapter

Package Contents

• VESA Mounting Bracket x 1

• M3 x 5 mm Screws x 4

• M4 x 12 mm Screws x 4

• M4 x 20 mm Screws x 4

VESA Mount Adapter for StarTech.com Docking Stations and Hubs

• Spacers x 4

• Quick-Start Guide x 1

Attaching a StarTech.com Docking Station or Hub

1. Align the on the with the on the Mounting Holes Adapter Mounting Holes

StarTech.com Docking Station Hub or . The recessed hole pattern should be facing

outward so the will t properly.M3 x 5 mm (Countersunk) Screws

2. Insert the four through the on the M3 x 5 mm Screws Mounting Holes Adapter

and into the on the or .Mounting Holes Startech.com Docking Station Hub

3. Using a (sold separately) tighten the , Phillips Head Screwdriver M3 x 5 mm Screws

being careful not to over-tighten the .M3 x 5 mm Screws

Mounting the Adapter (Flush)

1. Place the screen facing down on a at, clean, and secure surface.Monitor

2. Align the on the with the on the Mounting Holes Adapter VESA Mounting Holes

back of the .Monitor

3. Align the with the on the back of the VESA Monitor Mount VESA Mounting Hole

Adapter, Adapter VESA Monitor Mount sandwiching the between the and the

back of the . Monitor

4. Insert four of the through the and the M4 x 12 mm Screws VESA Monitor Mount

Adapter Mounting Holes Monitor and into the on the back of the .

5. Using a , tighten the , being careful Phillips Head Screwdriver M4 x 12 mm Screws

not to over-tighten the .M4 x 12 Screws

Mounting the Adapter (Recessed)

Note: The and provided with the can be installed on Spacers Screws Adapter

monitors with VESA mounting holes with a maximum depth of 7mm.

1. Place the screen facing down on a at, clean, and secure surface.Monitor

2. Place the four over the on the back of the .Spacers VESA Mounting Holes Monitor

3. Align the on the with the on the back on the Mounting Holes Adapter Spacers

Monitor.

4. Align the with the on the back of the VESA Monitor Mount VESA Mounting Hole

Adapter Adapter VESA Monitor Mount, sandwiching the between the and the

Spacers.

Produktspezifikationen

Marke:	StarTech.com
Kategorie:	Flachbildschirmunterstützung
Modell:	SSPMSVESA
Breite:	120 mm
Tiefe:	214 mm
Gewicht:	530 g
Produktfarbe:	Schwarz
Höhe:	3 mm
Material:	Stahl
Verpackungsbreite:	145 mm
Verpackungstiefe:	290 mm
Verpackungshöhe:	5 mm
Paketgewicht:	600 g
VESA-Halterung:	Ja
Anzahl Produkte pro Versandkarton:	20 Stück(e)
Länge des Versandkartons:	300 mm
Breite des Versandkartons:	240 mm
Höhe des Versandkartons:	240 mm
Kompatibilität:	DK30C2DPEP, DK30C2DPEPUE, DK30C2DPPD, DK30C2DPPDUE, TB3CDK2DP, TB3CDK2DPUE, HB31C3A1CS, HB31C4AS, HB31C2A1CGS
Schrauben enthalten:	Ja
Minimale VESA-Halterung:	75 x 75 mm
Maximale VESA-Halterung:	100 x 100 mm
