Quick Start Guide

Manual Revision: 09/06/2023

Product Design

Actual product may vary from photos

Front View

Rear View

Package Contents

• HDMI Splitter x 1

• Universal Power Adapter x 1

• Quick-Start Guide x 1

Requirements

Operating system requirements are subject to change. For the

latest requirements, please visit .www.startech.com/ST122HD202

Displays:

Displays are sold separately.

• HDMI Video Source Device x 1

• HDMI Displays x 2

Cables:

Cables are sold separately.

• HDMI Cables x 3

SKU #: ST122HD202

2-Port HDMI® Video Splitter - 4K 60Hz

Installation

Note: Before you begin the installation, ensure your HDMI source

device and each of the HDMI video displays are powered o.

1. Connect an , to the on the HDMI CableHDMI Input PortHDMI

Splitter. Connect the other end of the in the HDMI CableHDMI

Output Port on the . Video Source Device

2. Connect an , to the on the HDMI CableHDMI Out 1 PortHDMI

Splitter. Connect the other end of the in the HDMI CableHDMI

Input Port on the .Display

3. Repeat Steps 1 - 2 to connected a second display.

4. Connect the to the Universal Power AdapterDC 5V Power

Adapter Port on the . Connect the other end of Video Splitter

the to an .Universal Power AdapterAC Electrical Outlet

5. Turn on the .Video Source Device

6. Turn on the Displays

7. Verify that the video source is on the connected .Displays

EDID Switch

The features an HDMI SplitterExtended Display Identication

Data (EDID) Switch that allows you to use the EDID settings

from the display connected to the , or emulate HDMI Out 1 Port

standard EDID settings.

By default the EDID Switch is set to default (standard).

EDID Default Settings:

• 1920 x 1080 60HzResolution:

• 2 channel stereoAudio:

Using HDMI Out 1 Port EDID Settings

1. On the , change the from default to HDMI SplitterEDID Switch

display.

Note: To switch back to the Default EDID setting, switch from

display to default and follow Steps 2 - 3.

2. Disconnect the from the Universal Power AdapterAC Electrical

OutletHDMI Splitter and then disconnect it from the .

3. Reconnect the Universal Power Adapter to the DC 5V Power

Adapter Port on the . Connect the other end of Video Splitter

the to an .Universal Power AdapterAC Electrical Outlet

For the latest information, specications, and support visit www.startech.com/ST122HD202.

Power

LED

Input

LED

Output

LEDs

EDID

Switch

HDMI Out

Port 2

HDMI Out

Port 1

HDMI In

Port

DC 5V

Port
