Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: December 9, 2019

Product Diagram (SV211HDUA4K)

ComponentFunction

1Stereo Audio Connector

• Connect the from the Speaker Audio

Computer

2USB-A Connector

• Transmit the signal of a and KeyboardMouse

from the to the KVM SwitchComputer

3

Microphone Audio

Connector

• Connect the to the Microphone Audio

Computer

4Microphone Audio Port• Connect a Microphone

5USB HID Ports

• Connect a and KeyboardMouse

• (Optional) Connect USB Peripherals

6HDMI Port• Connect a HDMI Display

7HDMI Connector• Connect a HDMI Enabled Computer

2-Port USB HDMI® Cable KVM Switch w/ Audio and Remote Switch - 4K 60Hz

8LED Indicators• Indicates selection and activityComputer

9Stereo Audio Port• Connect Stereo Speakers

10Remote Switch

• A wired button used to switch between

Computer 12 and

• PressReleaseRemote Switch and the to

switch between and Computer 12

Requirements

• HDMI Enabled Computers x 2

• HDMI Display x 1

• USB HID Devices (Keyboard and Mouse) x 2

• (Optional) USB Peripherals x 2

• (Optional) Microphone x 1

• (Optional) Stereo Speakers or Headphones x1

• (Optional) Headset x 1

Note: A Headset may require the use of a Headset Adapter. Check with the

manufacturer of the Headset for more details.

• (Optional) 3.5 mm Audio Cables x 2

For the latest requirements and to view the full User Manual, please visit

www.startech.com/SV211HDUA4K.

Installation

Connect the Computers

1. Connect the built-in to the on Computer 1 HDMI ConnectorHDMI Port

Computer 1.

2. Connect the built-in to the on Computer 1 USB-A ConnectorUSB-A Port

Computer 1.

3. (Optional) Connect the built-in (green) to the Computer 1 Stereo Audio Connector

3.5 mm Stereo Audio PortComputer 1 on .

4. (Optional) Connect the built-in (pink) Computer 1 Microphone Audio Connector

to the on .3.5 mm Microphone Audio PortComputer 1

5. Repeat steps 1-4 to install .Computer 2

Connect the Console

1. Connect the to the USB-A Devices (Keyboard, Mouse, or USB Peripherals)USB-A

PortsKVM SwitchKeyboardMouse USB Cables on the using the built-in and or

USB-A Cables (sold separately).

7

1

2

3

5

6

5

9

10

8

4
