SY-ENC25042
2 2-BAY RAID Storage Enclosure .5”
User Manual
1 Introduction
1.1 Features
-Supports Big(JBOD), RAID0,RAID1,Normal mode
-Enhanced data protection and high-performances storage
-Automatic disk rebuild
-Support with USB3.0 high speed reach up to 5.0Gbps
-Supports plug and play
-Support mode select RAID switch by
1.2 Specications
Inner Interface: SATA
Outer Interface:USB3.0
Date Transfer rate: Support USB 3.0 super-speed (5Gbps),
Complies with USB 2.0 high speed (480Mbps), USB 1.1 Full speed ( Mbps) 12
Suitability:2 x 2.5” SATA I/II/III HDD
Supports Plug-play and Hot-plug
Power Supply: DC5V supplied by the Computer
What is RAID?
RAID (Redundant Array of Independent Disks) is a set of technology
standards for teaming disk drives to improve fault tolerance and performance
Why RAID?
Increased data protection. If in an unfortunate event where a drive fails,
the same data is preserved on the mirrored drive.
Intelligent array controllers can apply dierent types of RAID for dierent
hard disk drives.
Increased overall network system data capacity.
Increased I/O read/write eciency.
Setting the RAID Mode:
The RAID mode should be set before installing the drives and then rst
formatting the drives.
1. Open the rear cover and pull out the plastic frame from the
aluminum-shell.
2. Set the RAID switch and select your preferred RAID mode. There have 2
mode switch in the inner of the product, it can form 4 kinds of dierent
ways through these 2 switches, it can realize 4 kinds of dierent functions
as below:
3. Install the hard drives and replace the rear cover.
4. Connect the product into the PC USB 3.0 port by USB3.0 cable, LED HDD
should turn ON to indicate the SATA hard drives were detected.
5. Format the drives.
6. Done
Note: Changing the RAID mode will require you to re-format the drivers.Make
sure to backup all existing data first!
※
※
※
※※
Normal Mode (Non-Raid):
Normal mode is the default setting of HDD enclosure, and will not use any
RAID mode. In Normal mode, both of the two hard disks inside the enclosure
are in independent operation state, and also will be identied as two an
separate drives in the system explorer. Users can choose any hard drive for
storing les. If one hard drive is damaged, the other hard drives data will not be
aected.
※
※
※
※※
JBOD Mode (Spanning):
In JBOD mode two hard drives will be merged into one. Performance and
literacy speed will be the same as a single hard drive. The total capacity of the
portable hard drive is equal to the sum of the two hard drives combined. When
writing data to the JBOD array, the system will write date to the rst disk. When
the storage space of the rst disk is full the data will start be stored on the
second disk. If the data in the rst disk is damaged, then all data in the array
will be los t.
