Digital Filter

and

Interface

Oscillator

Voltage

Reference

Temperature

Sensor

Mux

PGA

12-bit

û

ADC

AIN0

AIN1

SCLK

CS

VDD

GND

DOUT/DRDY

DIN

ADS1018

0.1 F

AIN2

AIN3

3.3 V

3.3 V

3.3 V

Product

Folder

Order

Now

Technical

Documents

Tools &

Software

Support &

Community

Reference

Design

AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,

intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.

ADS1018

SBAS526D–NOVEMBER2012–REVISEDSEPTEMBER2019

ADS1018Ultrasmall,Low-Power,SPI™-Compatible,12-Bit,

Analog-to-DigitalConverterWithInternalReferenceandTemperatureSensor

1

1Features

1

•UltrasmallX2QFNPackage

2mm×1.5mm×0.4mm

•12-BitNoise-FreeResolution

•WideSupplyRange:2Vto5.5V

•LowCurrentConsumption:

–ContinuousMode:Only150μA

–Single-ShotMode:AutomaticPower-Down

•ProgrammableDataRate:128SPSto3300SPS

•Single-CycleSettling

•InternalLow-DriftVoltageReference

•InternalTemperatureSensor:

2°C(max)Error

•InternalOscillator

•InternalPGA

•FourSingle-EndedorTwoDifferentialInputs

•SpecifiedTemperature:–40°Cto+125°C

2Applications

•TemperatureMeasurement:

–ThermocoupleMeasurement

–Cold-JunctionCompensation

–ThermistorMeasurement

•PortableInstrumentation

•FactoryAutomationandProcessControls

3Description

TheADS1018isaprecision,low-power,12-bit,noise-

free,analog-to-digitalconverter(ADC)thatprovides

allfeaturesnecessarytomeasurethemostcommon

sensorsignalsinanultrasmall,leadless,X2QFN-10

orVSSOP-10package.TheADS1018integratesa

programmablegainamplifier(PGA),voltage

reference,oscillatorandhigh-accuracytemperature

sensor.Thesefeatures,alongwithawidepower-

supplyrangefrom2Vto5.5V,maketheADS1018

ideallysuitedforpower-andspace-constrained,

sensor-measurementapplications.

TheADS1018performsconversionsatdataratesup

to3300samplespersecond(SPS).ThePGAoffers

inputrangesfrom±256mVto±6.144V,allowing

bothlargeandsmallsignalstobemeasuredwith

highresolution.Aninputmultiplexer(mux)allows

measurementoftwodifferentialorfoursingle-ended

inputs.Thehigh-accuracytemperaturesensorisused

forsystem-leveltemperaturemonitoring,orcold-

junctioncompensationforthermocouples.

TheADS1018operateseitherincontinuous-

conversionmode,orinasingle-shotmodethat

automaticallypowersdownafteraconversion.

Single-shotmodesignificantlyreducescurrent

consumptionduringidleperiods.Dataaretransferred

throughaserialperipheralinterface(SPI™).

DeviceInformation

(1)

PARTNUMBERPACKAGEBODYSIZE(NOM)

ADS1018

X2QFN(10)1.50mm×2.00mm

VSSOP(10)3.00mm×3.00mm

(1)Forallavailablepackages,seethepackageoptionaddendum

attheendofthedatasheet.

K-TypeThermocoupleMeasurement

UsingIntegratedTemperatureSensorforCold-JunctionCompensation
