Pacific

V-GTX 9

Series

VGA Water Block

This product is intended for installation only by expert users. Please consult with a qualified technician for installation.

Improper installation may result in damage to your equipment.

Before you start using this product please follow these basic guidelines:

1. Please carefully read through the instruction manual before beginning the installation process.

2. Please remove your graphics card from your motherboard to insure the safest process and in order to prevent any

possible damages to your CPU and motherboard.

3. It is strongly recommended to use market proven pre-mix coolant, such as Thermaltake Coolant 1000.

Ax1

Bx6

Cx1

Dx 4

Fx 2

GHx1 x1

Ex1

2

Remove original VGA stock cooler (Remove the screws circled on the

diagram. All heat sink assembly screws should be removed)

When installing the water block, carefully position the water

block with the preinstalled standoffs on the graphics card.

Terminal installation

Remove the power connector

Parts List

7

Reference Design

E

© 2016 Thermaltake Technology Co., Ltd. All Rights Reserved. www.thermaltake.com

1

Option

C

Apply thermal compoundCut the thermal pads to the dimensions listed and place them on the spots shown on the diagram.

D

a

b

b

b

81 mm

67 mm

67 mm

67 mm

a

b

b

b

4

5

3

Clean the original thermal compound off the GPU

die. (Carefully detach the original stock cooler after

removing all screws securing the cooler to the board)

E

H

G

F

B

Transparent
