Seite 1/1
MIXER/PREAMPLIFIER - MODEL 207t
Eurorack 200 series
Specifications:
Size: 28 HP - Depth: 28mm
Power: +12V 90mA / -12V 85mA
The Buchla 207t mixer six inputs two main outputs monitor output.has and as well as a
At the bottom right side of the mixer is a and gain pot The microphone input jack takes a microphone input with preamplifier .
1/4” TRS phone plug. Above it is the gain switch and knob which set the gain of the preamp. has two dierent The switch
ranges, and 55db 70db to cover most microphones that needs to be boosted to eurorack signal levels. The microphone input
can also be used for a signal from some other source such as an electric guitar or line level electric piano.
On the top right of the mixer, is one channel output jack, and one channel output jack, two mono "left” "right” MONITOR
outputs, and one stereo EXPANSION IN jacks. These last two jacks are actually a pair of inputs without attenuators, assign
control, or access to the MONITOR output. The jack on the left goes directly to the "left" output and the left right goes to the
"right" output. These inputs can be used to link the two mixers to form one 12 in, 2 out" mixer. To do this simply patch the SIGNAL
outputs of one mixer into the EXPANSION IN inputs of the other.
Horizontally on the bottom are the six mixer signal input jacks ('A" through "F").
Above these are s. Putting any of these switches in the up position sends the signal from that input six yellow MONITOR switche
to the MONITOR output on the mixer. The , when up, send the respective signal to the main SIGNAL outputs. six blue switches
The sliders are attenuators on the input signals going to the SIGNAL outputs. They have no eect on any signal going to the
MONITOR output.
Above the four centre sliders are which pan the signal between the "left" and "right" outputs. The input ASSIGNMENT pots
channels on either side of each mixer ("A" and "F") feature voltage controlled assign. Without any control voltage channel "A" is
assigned to the left output and channel "F" goes to the right output. As a control voltage increases the signal pans to the other
output channel. The two LED's below each control voltage input indicate which channel the signal is going to.
