Thank you for purchasing TOA's Headset Microphone.

Please carefully follow the instruction in this manual to ensure proper use of your equipment.

WH-4000A

WH-4000H

HEADSET MICROPHONES

INSTRUCTION MANUAL

1. GENERAL DESCRIPTION

The TOA WH-4000A and WH-4000H are headset

microphones of a cardioid pick-up pattern, featuring

a lightweight design. Besides, the WH-4000A is

equipped with an adjustable band to fix the headset

on your head.

2. NOMENCLATURE

[WH-4000A]

Plug lock

GooseneckWindscreen

Adjustable band

Frame

Microphoneø3.5 mm

(0.14 ")

[WH-4000H]

Plug lock

GooseneckWindscreen

Frame

Microphone

ø3.5 mm

(0.14 ")

• Wearing the headset

Position the adjustable band

either above or below the

frame to provide the greatest

comfort and stability.

3. PRECAUTION

Be sure to keep the windscreen attached to the

microphone while in use.

Doing otherwise allows sweat or spit to directly get

into the microphone, possibly causing its failure.

5. SPECIFICATIONS

Type Electret condenser type

Directivity Unidirectional

Sensitivity –66 dB ±3 dB

(0 dB = 1 V/0.1 pa, 1 kHz)

Maximum 120 dB SPL

Input Level

Cord Length1.3 m (4.27 ft)

Terminal ø3.5 mm (0.14 ") monaural plug

FinishAdjustable band (WH-4000A only):

EVA, black

Frame:

Stainless, black (silicon rubber)

Gooseneck:

Iron, chrome-plated, black

(shrink tube)

Weight 50 g or 1.76 oz (cable included)

Note: The design and specifications are subject to change

without notice for improvement.

133-07-221-9G

4. HOW TO USE

•By adjusting the gooseneck, position the

microphone with the supplied windscreen slightly

off the front of your mouth, and 3 – 5 cm away from

your mouth for the best sound reproduction. When

the microphone is too close to your mouth or you

speak too loud, speech clarity will be impaired,

making it hard for the audience to hear

announcements.

•Place the headset frame around the head so that

the frame and adjustable band are horizontal

across the back of the head and the ends of the

frame fit over.

URL: http://www.toa.jp/

This product is an expendable item. No warranty is provided for any trouble except incipient failure.
