Seite 1/2
Wire Your Switch
Disconnect wires from the old switch.
Turn o the circuit breaker. Then remove
the old wallplate of the wall switch and
label the wires.
1
2
Connect the wires to the smart switch as
shown below.
Note: No need to distinguish between and wires.Line Load
3
Ground: Usually green or copper.
Neutral: Usually white, not connected to the dumb switch.
Line/Load: Usually black, and connected to the dumb
switch.
If you are unsure, consult a qualied electrician.
Line up the switch with the mounting
holes. Secure it with screws.
4
Attach the wallplate and turn on the
circuit breaker. Then the wiring is nished.
5
Power
Source
To Light
Set Up Your Switch
STEP 2
SET UP
Tap the button in the app.
• If your device is white, select Smart
Switches > Smart Switch (Wi-Fi).
• If your device is black or almond, select
Smart Switches > Smart Switch (BLE).
And then follow app instructions to complete
setup.
DOWNLOAD APP
Get the app from the App Store Kasa Smart
or Google Play.
STE 1P
OR
©2023 TP-Link 7106510678 REV6.1.0
Smart Wi-Fi Light Switch
Quick Start Guide
*Images may dier from your actual product.
Appearance Button Explanations
Restart
Reset
Press and hold for about until the LED 5s
blinks amber and green to reset Wi-Fi
while keeping other settings.
Press to restart your switch.
Press and hold for about until the 10s
LED blinks amber to restore to factory
default settings.
LED Status
Starting up.Solid amber
Blinking amber
Blinking green
White
Solid red
Stay green for 30s
Blinking amber & green
Connecting to Wi-Fi.
Device resetting.
Light fixture is off.
Disconnected from Wi-Fi.
Connected to Wi-Fi.
On/O
Button
Restart
LED
Reset
Specications
Safety Notice
Before installing, servicing or removing the switch, read and follow
all safety precautions including the following:
• CAUTION – Risk of Electric Shock – More than one disconnect
switch may be required to de-energize the equipment before
servicing. A circuit breaker which disconnects the Line and
Neutral conductor simultaneously is suitable. Ensure power is o
at the circuit breaker before removing or installing any switch.
Use a non-contact voltage tester to ensure the power is o.
• The Smart Switch must be installed and used in accordance with
the National Electric Code (NEC) or your local electrical code. If
you are unfamiliar with these codes and requirements, or are
uncomfortable performing the installation, consult a qualied
electrician.
• Do not install the Smart Switch with wet hands or when standing on
wet or damp surfaces.
• Install only in a suitable UL Listed outlet box (suitable dimensions:
H > 2.95 in./75 mm, W > 1.81 in./46 mm, D > 2 in./51 mm).
Rating: 100-120 V~ 50/60 Hz
Load: 15 A General Use
600 W Max Incandescent/Halogen, 1/6HP Motor
Operation temperature: 0~40℃
Method of mounting included: Independently
mounted (Vertically position only);
Operating control, Type 1.C action
Pollution Degree 2, Rated Impulse Voltage 2500V
Software Class A, NEMA Type 1
Recommended Load Types:
LED: 100W ≤ Ceiling Fan: ≤ 120 W
For technical support, the user guide and other
information, visit https://www.tp-link.com/support/.
Support
Ready for setup;
Resetting Wi-Fi.
Haute tension : débranchez l'alimentation électrique au
niveau du disjoncteur avant l'utiliser
High Voltage-Disconnect power supply at the circuit
breaker before servicing
CAUTION
MISE EN GARDE
Third-Party Services
Kasa works with Alexa, Google Assistant, and
other third-party services to control your switch
by voice. Go to in the Me > Third-Party Services
Kasa Smart app to integrate third-party services.
For step-by-step setup instructions, please visit:
• Google Home Assistant:
https://www.tp-link.com/support/faq/1534/
• Amazon Alexa:
https://www.tp-link.com/support/faq/944/
