Quick Installation Guide
Wall Plate Wi-Fi 6 Extender
Note: This guide uses EAP673-Extender for demonstration. Images may
dier from your actual product.
©2024 TP-Link 7106511194 REV1.0.0
Hardware Overview
1Power On2
LED Indicator
On: Working normally/Initializing.
O: Working abnormally/Power o/LED is turned o.
Flash:
•Flash twice: Initialization is complete.
•Flash once per second: The EAP is upgrading.
•The EAP is resetting or the Omada Quick ash:
Controller is locating the EAP.*
* When the Locate feature is activated in the Omada Controller, the
LED will ash quickly for 10 minutes to help you locate and identify
the device. You can disable this feature manually to stop the device
from ashing.
• The EAP is in isolated state.Sustained ash:
RESET Button
With the EAP powered on, press and hold the button for
about 5 seconds until the LED ashes, then release the
button. The EAP will restore to factory default settings.
LED/Wi-Fi Button
When the EAP is working in Standalone Mode and
enabled with Wi-Fi Control, press the button to turn on/o
both the Wi-Fi and LED. In other cases, press the button
to turn on/o the LED only.
LAN Port
Connect a wired device via an Ethernet cable for network
access.
LED/Wi-Fi Button
RESET Button
LAN Port
LED
Power
Outlet
Plug
Plug the EAP into a power outlet.
Note: For safety, only plug the extender in the direction as shown
below.
Set Up
3
Choose a method to set up your EAPs:
• Method 1: Controller Mode
To congure and manage EAPs in batches on a
central platform, namely Omada Controller.
• Method 2: Standalone Mesh Mode
To build an Omada Mesh network to congure and
manage EAPs.
Business CommunityDownload CenterSetup Videos
Tip:
You can also set up the EAP in AP Mode to transform your
existing wired network to a wireless one. For details, refer to the
EAP’s user guide at
https://www.tp-link.com/support/download/?type=smb
