Interface Description

As a WAN port (by default): For connecting it to your

modem, the Ethernet outlet, or for other internet

services.

As a LAN port (need to set manually): For connecting

your PC or other wired devices to the router.

For connecting your PC or other wired devices to the

router.

Use this USB 3.0 port to connect your 3G/4G/5G

USB modem, mobile device, or USB storage device

to the router.

For connecting the USB-C charger provided in the

package. To avoid potential damage, it is recommended

to use the provided power adapter or a 5V/3A adapter

that meets the certication and voltage standards.

WAN Port

LAN Port

USB 3.0

Port

Power Port

Appearance

Set Up Your Router

LED Indication

IndicationStatus

The router has started up but is disconnected from

the internet.

Solid Red

Blinking Red

The router is being reset. Do not power o your

router.

Blinking Blue

The router is starting up / being upgraded /

establishing the WPS connection.

The router is connected to the internet or the main

network, or the WPS connection is successfully

established.

Solid Blue

©2025 TP-Link 7100000229 REV1.0.0

Images may dier from your actual product.

AX1500 Wi-Fi 6 Portable Router

Quick Installation Guide

4. Launch a web browser and enter http://tplinkwifi.net

or http://192.168.0.1in the address bar.Create a

password to log in.

http://tplinkwi.net

New Password:

Let’s Get Started

Conrm Password:

1.Power on the router.

2. Wait until the router’s LED turns solid (blue or red) before

moving on.

3. Connect your device to the router (wireless or wired).

• Wireless: Connect your device to the router’s Wi-Fi. The

default wireless network names (SSIDs) and wireless

password are printed on both the Wi-Fi info card and the

label at the bottom of the router.

• Wired: Turn o the Wi-Fi on your device and connect to

the LANport of the router with an Ethernet cable.

LED

WPS/Reset Button

Action Button

USB

Port

WAN

Port

LAN

Port

Power

Port

Button Description

The customizable action button oers you a

physical shortcut to control a variety of functions,

including Wi-Fi, LED and VPN Merge.

Press the button for 1 second and immediately

press the WPS button on your client to start the

WPS process.

Press and hold the button for about 6 seconds until

the LED blinks red to reset the router to its factory

default settings.

WPS/Reset

Button

Action

Button

Method ONE: Via the Tether App

1. Download the Tether app via Apple Store or Google Play,

or simply scan the QR code.

Scan for TetherTether

or

2. Open the Tether app and log in with your TP-Link ID.

Note: If you don’t have an account, create one first.

4. Choose how you would like to connect your router to the

internet. Then follow the steps to complete the setup.

• Connect via Ethernet: The router gets internet via an Ethernet

cable connected to the existing wired network.

• Connect via Wi-Fi: The router gets internet via an existing

public Wi-Fi and turns it into a private network.

• Connect via USB Tethering: The router gets internet via a USB

cable connected to a mobile device (with a SIM card inserted).

• Connect via a USB Modem: The router gets internet from a

USB modem (with a SIM card inserted).

5. Choose how you would like to connect your router to the

internet. Then follow the steps to complete the setup.

• Connect via Ethernet: The router gets internet via an Ethernet

cable connected to the existing wired network.

• Connect via Wi-Fi: The router gets internet via an existing public

Wi-Fi and turns it into a private network.

• Connect via USB Tethering: The router gets internet via a USB

cable connected to a mobile device (with a SIM card inserted).

• Connect via a USB Modem: The router gets internet from a USB

modem (with a SIM card inserted).

Note: If the login window does not appear, please refer to

Q1 of Need Help? in this guide.

Method TWO: Via a Web Browser

To enjoy a more complete service from TP-Link, bind your TP-Link ID to

the router.

To enjoy a more complete service from TP-Link, bind your TP-Link ID to

the router.

3. Tap the button in the Tether app and select Add a Router.

Note: Due to Tether app updates, your actual user interface and

pathway may differ from those depicted here.

Note: If you want to use it in Access Point/Extender Mode, go to More >

Operation Modes to switch the mode as needed. For Client Mode, follow

Method TWO to switch the mode on the web page.

Note: If you want to use it in Access Point/Extender/Client Mode,

exit the quick setup, and click Change Mode on top of the page,

then select the mode as needed.

*Router network mode

compatibility in the Tether

app may vary between app

versions.

Add Device

Create a new Wi-Fi network.

Add a Router

Extend your existing wireless network

with a range extender.

Add a Range Extender

>

>
