Owner’s Manual

1U Short-Depth Rackmount Console

with 19” Display

For KVM Switch or Server

Model: B021-000-19-SH

(Series Number: AGCB6533)

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

1. Introduction 2

2. Important Safety Instructions 2

3. System Components & Compatibility 2

4. Features 3

5. Connection 4

6. Storage & Service 5

7. Speciﬁcations 5

8. Warranty & Product Registration 5

Español 6

Français 11

Русский 16

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

1. Introduction

The B021-000-19-SH 1U Short-Depth Rackmount Console features an integrated LCD panel, full keyboard and touch pad in a 1U

rackmountable housing. It is designed for use with a server or a KVM switch with PS/2 or USB console port connectors. The B021-000-19-SH’s

compact design permits installation in short-depth enclosures. Features include:

• Rackmount console combines a 19-inch LCD display, keyboard and touch pad in an integrated 1U rackmountable housing

• Sleep mode is automatically invoked when the monitor cover is closed

• Supports resolutions of up to 1366 x 768 pixels

• Can be used with any device that includes PS/2 or USB console port connectors

• Rackmountable in short-depth enclosures down to 19 inches

2. Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the installation and operation of this product.

Failure to comply may invalidate the warranty and cause property damage and/or personal injury.

Installation Warnings

• Install the Console in a controlled indoor environment, away from moisture, temperature extremes, ﬂammable liquids and gasses, conductive

contaminants, dust and direct sunlight.

• Operate the Console at indoor temperatures between 32° F and 104° F (0° C and 40° C).

• When connecting the Console to the facility’s power supply circuit, ensure that the circuit is not overloaded.

• Use only the power adapter (12V DC limited power source) provided with the console.

Rackmount Warnings

• Ensure there is adequate airﬂow within the rack.

• Mount the Console evenly within the rack to eliminate potentially hazardous uneven mechanical loading conditions.

• Ensure that all rackmount equipment is reliably grounded.

Connection Warnings

• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life

support equipment or to signiﬁcantly affect its safety or effectiveness is not recommended. Do not use this equipment in the presence of a

ﬂammable anesthetic mixture with air, oxygen or nitrous oxide.

• Ensure that the cables used with the Console are not close to any sources of electrical noise interference such as ﬂuorescent lights, HVAC

systems or motors.

• Ensure that the distance between any computer and the Console does not exceed 33 ft. (10 m).

Maintenance Warnings

• The Console does not require routine maintenance. There are no user-serviceable parts inside. Only authorized service personnel should open

the case for any reason.

• Disconnect the unit from AC input power before servicing.

3. System Components & Compatibility

Package contains:

• B021-000-19-SH 1U Short-Depth Rackmount Console

• Mounting Hardware

• PS/2 Cable Kit

• USB to PS/2 Adapter

• AC/DC Power Adapter

• Owner’s Manual

The B021-000-19-SH supports most servers and KVM switches with USB console port connectors.

Produktspezifikationen

Marke:	Tripp Lite
Kategorie:	Schalter
Modell:	B021-000-19-SH
Bildschirmdiagonale:	19 "
Breite:	476.2 mm
Tiefe:	482.6 mm
Gewicht:	12310 g
Produktfarbe:	Schwarz
Höhe:	44.4 mm
Verpackungsbreite:	586.7 mm
Verpackungstiefe:	613.9 mm
Verpackungshöhe:	121.9 mm
Paketgewicht:	14400 g
Display:	LCD
Ursprungsland:	Taiwan
Anzahl Produkte pro Versandkarton:	1 Stück(e)
Gewicht Versandkarton:	15450 g
Länge des Versandkartons:	614.9 mm
Breite des Versandkartons:	595.1 mm
Höhe des Versandkartons:	154.9 mm
Schnittstelle:	PS2/USB
Abmessungen (BxTxH):	438.1 x 482.6 x 44.4 mm
Tastatur - Tastenanzahl:	104
Weitere Anschlüsse:	1 x HD15 F
Höhe (in Rack Units):	1
Display-Auflösung:	1280 x 1024 Pixel
