Use of this equipment in life support applications where

failure of this equipment can reasonably be expected to cause

the failure of the life support equipment or to significantly

affect its safety or effectiveness is not recommended.Do not

use this equipment in the presence of a flammable anesthetic

mixture with air,oxygen or nitrous oxide.

Installation

Mount YourSurge SuppressororPowerStrip (Optional Installation): If

desired, mount your surge suppressor or power strip on a wall or other sturdy,

vertical surface. However, you must mount the surge suppressor or power strip

prior to connecting your equipment. Place a sheet of paper over the product’s

mounting holes and mark their centers with a push pin. Next, place this

template over the desired area and mark with the push pins. Install screws

(user supplied) into the marks until ¼ in. (0.5 cm.) of the screw heads are

exposed. Mount the product over the screw heads and slide into place.

Connect YourSurge SuppressororPowerStrip to the AC PowerLine:

Plug the product’s power cord into a standard, 3-wire grounded 120VAC,

60 Hz. outlet.

Turn YourSurge SuppressororPowerStrip ON: Press the product’s power

switch to “ON”. All models feature an illuminated switch.

Check YourSurge Suppressor’s Diagnostic IndicatorLight (Available on

Surge SuppressorModels Only): If your surge suppressor features a

diagnostic LED, check it prior to connecting your equipment. It will indicate

operating conditions when the surge suppressor is plugged into a live 120V

AC outlet and the surge suppressor’s power switch is on.

“PROTECTED” LED:Indicates the surge suppression components are

intact and providing complete protection against surges. If this LED does

not illuminate, some of the surge suppression components are not

functioning, and the unit should be replaced. Call Tripp Lite Customer

Support at (773) 869-1234.

Connect YourEquipment to the Surge Suppressor’s orPowerStrip’s AC

Outlets: Plug your equipment’s power cords (including 2-wire devices) into

the product’s AC outlets. All models feature integrated safety covers which

cover the outlets when not in use. Models also feature special widely-spaced

outlets to accommodate transformers without covering other outlets. DO NOT

plug in extension cords. DO NOTOVERLOAD the product’s outlets. The

product can accommodate a total equipment load of up to 15 amps (whether

plugged into a single outlet or spread out over multiple outlets). If the load on

the product exceeds 15 amps, the integrated circuit breaker within the

ON/OFF switch or the GFCI plug (depending on the model) will trip and the

outlets will stop providing power. If the circuit breaker or GFCI plug trips,

reduce the load by unplugging some devices. For models that include an

ON/OFF switch with an integrated circuit breaker, rock the switch from the

“OFF” back to the “ON” position to reset. For models that include the GFCI

plug, simply press the “RESET” button to reset. You can also test that the

GFCI is functioning properly by pressing the “TEST” button. The unit should

trip to indicate proper function. If so, press the “RESET” button to reset. If the

unit does not trip after pressing the reset button, call Tripp Lite Customer

Support at (773) 869-1234.

FCC Part 68 Notice

(United States Only)

If your Modem/Fax Protection causes harm to the telephone network, the telephone company may temporarily discontinue your

service. If possible, they will notify you in advance. If advance notice isn't practical, you will be notified as soon as possible. You

will be advised of your right to file a complaint with the FCC. Your telephone company may make changes in its facilities,

equipment, operations or procedures that could affect the proper operation of your equipment. If it does, you will be given advance

notice to give you an opportunity to maintain uninterrupted service. If you experience trouble with this equipment's Modem/Fax

Protection, please call Tripp Lite Technical Support at (773) 869-1234 for repair/warranty information. The telephone company may

ask you to disconnect this equipment from the network until the problem has been corrected or you are sure the equipment is not

malfunctioning. There are no repairs that can be made by the customer to the Modem/Fax Protection. This equipment may not be

used on coin service provided by the telephone company. Connection to party lines is subject to state tariffs. (Contact your state

public utility commission or corporation commission for information.)

Lifetime Limited Warranty

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and

workmanship for its lifetime. If the product should prove defective in material or workmanship within that period, Seller will repair or

replace the product, in its sole discretion. Service under this Warranty can only be obtained by your delivering or shipping the product

(with all shipping or delivery charges prepaid) to: Tripp Lite, 1111 W. 35th St., Chicago, IL60609. Seller will pay return shipping charges.

The warranties of all TRIPPLITE surge suppressors are null and void if they have been connected to the output of any UPS system.

The warranties of all TRIPPLITE UPS Systems are null and void if a surge suppressor has been connected to its output receptacles.

THIS WARRANTYDOES NOTAPPLYTO NORMALWEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE

OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTYEXPRESSLYSETFORTH

HEREIN. EXCEPTTO THE EXTENTPROHIBITED BYAPPLICABLE LAW, ALLIMPLIED WARRANTIES, INCLUDING ALL

WARRANTIES OF MERCHANTABILITYOR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTYPERIOD SETFORTH

ABOVE; AND THIS WARRANTYEXPRESSLYEXCLUDES ALLINCIDENTALAND CONSEQUENTIALDAMAGES. (Some states

do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or limitation of incidental

or consequential damages, so the above limitations or exclusions may not apply to you. This Warranty gives you specific legal

rights, and you may have other rights which vary from jurisdiction to jurisdiction.)

TRIPPLITE; 1111 35th St.; Chicago, IL60609

WARNING:The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the

use intended. Since individual applications are subject to great variation, the manufacturer makes no representation or warranty

as to the suitability or fitness of these devices for any specific application.

Policy of Tripp Lite is one of continuous improvement. Specifications are subject to change without notice.

Regulatory Compliance Identification Numbers

For the purpose of regulatory compliance certifications and identification, your Tripp Lite product has been assigned a unique

series number. The series number can be found on the product nameplate label, along with all required approval markings and

information. When requesting compliance information for this product, always refer to the series number. The series number

should not be confused with the marking name or model number of the product.

Warranty Registration

Visit www.tripplite.com/warranty today to register the warranty for your new Tripp Lite product. You'll be automatically entered into

a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Ultimate Lifetime Insurance Policy

(Select models:This is a limited warranty valid in the U.S.and Canada only.)

Tripp Lite warrants, for the lifetime of the product, (at Tripp Lite's option) to repair or replace (on a pro rata basis) directly connected

equipment that is damaged due to power transients while properly connected to Tripp Lite products offering the Ultimate Lifetime

Insurance Policy. Power transients include spikes and surges on the AC power, data or telephone lines that the Tripp Lite products

have been designed to protect against (as recognized by industry standards). The following four paragraphs are conditions that must

be complied with before the warranty becomes valid; failure to comply with these requirements will void the warranty.

AC Power Line Transients: To claim damages, the Tripp Lite product must be plugged into a properly wired and grounded outlet. No

extension cords or other electrical connections may be used. The installation must comply with all applicable electrical and safety

codes set forth by the National Electrical Code (NEC). Except as provided above, this warranty does not cover any damage to

properly connected electronic equipment resulting from a cause other than an "AC power transient". If user meets all of the above

requirements, Tripp Lite will repair or replace (at Tripp Lite's option) equipment up to the specified value (See Ultimate Lifetime

Insurance Policy Limits). No coverage is allowed for damage entering from telephone or data lines, unless they are separately

protected, as described below.

Telephone and Data Line Transients: Tripp Lite will repair or replace directly connected equipment that is damaged by transients on

telephone and/or data lines only when all such paths are protected by a Tripp Lite protection product(s) and the AC power (utility) line

is simultaneously protected by a Tripp Lite power protection device (UPS, surge suppressor or line conditioner) with Ultimate Lifetime

Insurance coverage. Additional telephone and/or data line connected devices downstream must have their own telephone and/or

dataline protectors.

Reimbursement dollar limits will be equal to that of the Tripp Lite power protection protector. Coverage is excluded where a suitable

environment for the protection device is not provided, including, but not limited to, lack of a proper safety ground. Telephone service

equipment must also include a properly installed and operating "primary protection" device at the telephone service entrance (such

devices are normally added during telephone line installation).

All above warranties are null and void if the Tripp Lite product has been improperly installed, tampered with or altered in any way, or

if the connected equipment was not used under normal operating conditions or in accordance with any labels or instructions. All claims

under this warranty must be submitted in writing to Tripp Lite within 30 days of the occurrence or the claim will not be considered.

This warranty does not include damage resulting from accident or misuse, and applies to the domestic (USA& Canada) use of these

products only. Tripp Lite reserves the right to determine whether the damage to the connected equipment is due to malfunction of the

Tripp Lite product by requesting the equipment in question be sent to Tripp Lite for examination. This policy is above and beyond,

only to the extent needed, of that provided by any coverage of connected equipment provided by other sources, including, but not

limited to, any manufacturer's warranty and/or any extended warranties.

EXCEPTAS PROVIDED ABOVE, TRIPPLITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES

OF MERCHANTABILITYAND FITNESS FOR APARTICULAR PURPOSE. Some states do not permit limitation or exclusion of

implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to purchaser. EXCEPTAS PROVIDED ABOVE,

IN NO EVENTWILLTRIPPLITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTALOR CONSEQUENTIALDAMAGES

ARISING OUTOF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITYOF SUCH DAMAGE. Specifically, Tripp

Lite is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of

data, costs of substitutes, claims by third parties or otherwise. Coverage also does not apply to connected medical and industrial

equipment.

To receive service under this warranty, you must be the original purchaser/user of the product in question. You must obtain a Returned

Material Authorization (RMA) number from Tripp Lite. Products must be returned to Tripp Lite with transportation charges prepaid and

must be accompanied by a brief description of the problem encountered and proof of date and place of purchase.

CAUTION!DO NOT connect to an ungrounded outlet.DO NOT use with 2-wire extension cords or adapters.This productis designed

for indoor use only.Install the product away from heat-emitting appliances such as radiators or heat registers.Do not install where

excessive moisture is present.Do not plug extension cords into it.Never install electrical, telephone, network or coaxial wiring

during a lightning storm.Do not drill into any part of the housing or open the housing for any reason.There are no user-

serviceable parts inside.The Surge Suppressors feature an internal protection that will disconnect the surge-protective

component at the end of its useful life but will maintain power to the load—now unprotected.

1111 W. 35

th

Street Chicago, IL60609

Customer Support: (773) 869-1234

www.tripplite.com

IMPORTANT SAFETY INSTRUCTIONS.SAVE THESE INSTRUCTIONS.

Owner’s Manual

Protect It!

™

Safety Surge Suppressors

& Power It!

™

Safety Power Strips

Copyright © 2007. All rights reserved. Protect It!

™

and Power It!

™

are trademarks of Tripp Lite.

WARRANTY

REGISTRATION:

register online today for a

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

200707099 93-2717 Protect It SAFETY OM.qxd 8/24/2007 4:52 PM Page 1
