Seite 1/4

1 947839
ISSUE1
VIP-172ALRevolution® Compliant
IP DoorPhone/Intercom
INTRODUCTION
The VIP-172AL Revolution® compliant IP
Talkback DoorPhone/Intercomallows
communication via the Intrado Revolution server,
SIP based telephone systems or to Valcom IP
gateways over an IP-based network. The -ST
model includes a standard stainless steel
faceplate, while the -VRSS model includes a
heavier stainless steel faceplate and additional
vandal resistant features.
SPECIFICATIONS
Access Methods
•Intrado Revolution server
•SIP – enabled telephone system
•Standalone phones using Valcom gateways
•Valcom M Cast Page Group
Features
•1 Form C relay
•Network activity LEDs
•Power over Ethernet (PoE) 802.3af
compatible
Dimensions/Weight:
VIP-172AL-VRSS-SA
•4.5” H x 4.5" W x 1.75" D
(11.43cm H x 11.43cm W x 4.45cm D)
•Weight: 1.68 lbs. (0.76 kg)
VIP-172AL-ST-SA
•4.5” H x 4.5" W x 1.3" D
(11.43cm H x 11.43cm W x 3.3cm D)
•Weight: 0.55 lbs. (0.25 kg)
Network Interface
•1.62” H x 5.63” W x 3.45” D
(4.11 cm) x (14.30 cm) x (8.73 cm)
•with brackets – 8.22” W (20.87 cm)
•Weight: 2.10 lbs. (0.95 kg)
VIP-172AL-ST VIP-172AL-VRSSNetwork Interface
Nominal Specifications
Input Impedance: 600 Ohms
Input Level: -10dBm
Output Impedance: 600 Ohms
Output Level: -10dBm nominal
Relay Current: 1 AMP @ 24VDC
Nominal Power Requirements
Via 802.3af PoE Ethernet Switch: Class 3
Environment
Network Interface:
Temperature: 0 to +40° C
Humidity: 0 to 85% non-precipitating
VIP-172AL Door plate:
Suitable for indoor or outdoor installation
Precautionary Designations
CAUTION: To reduce the risk of electric shock,
Do not remove cover.
No user serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
