1 947839

ISSUE1

VIP-172ALRevolution® Compliant

IP DoorPhone/Intercom

INTRODUCTION

The VIP-172AL Revolution® compliant IP

Talkback DoorPhone/Intercomallows

communication via the Intrado Revolution server,

SIP based telephone systems or to Valcom IP

gateways over an IP-based network. The -ST

model includes a standard stainless steel

faceplate, while the -VRSS model includes a

heavier stainless steel faceplate and additional

vandal resistant features.

SPECIFICATIONS

Access Methods

•Intrado Revolution server

•SIP – enabled telephone system

•Standalone phones using Valcom gateways

•Valcom M Cast Page Group

Features

•1 Form C relay

•Network activity LEDs

•Power over Ethernet (PoE) 802.3af

compatible

Dimensions/Weight:

VIP-172AL-VRSS-SA

•4.5” H x 4.5" W x 1.75" D

(11.43cm H x 11.43cm W x 4.45cm D)

•Weight: 1.68 lbs. (0.76 kg)

VIP-172AL-ST-SA

•4.5” H x 4.5" W x 1.3" D

(11.43cm H x 11.43cm W x 3.3cm D)

•Weight: 0.55 lbs. (0.25 kg)

Network Interface

•1.62” H x 5.63” W x 3.45” D

(4.11 cm) x (14.30 cm) x (8.73 cm)

•with brackets – 8.22” W (20.87 cm)

•Weight: 2.10 lbs. (0.95 kg)

VIP-172AL-ST VIP-172AL-VRSSNetwork Interface

Nominal Specifications

Input Impedance: 600 Ohms

Input Level: -10dBm

Output Impedance: 600 Ohms

Output Level: -10dBm nominal

Relay Current: 1 AMP @ 24VDC

Nominal Power Requirements

Via 802.3af PoE Ethernet Switch: Class 3

Environment

Network Interface:

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

VIP-172AL Door plate:

Suitable for indoor or outdoor installation

Precautionary Designations

CAUTION: To reduce the risk of electric shock,

Do not remove cover.

No user serviceable parts inside.

Refer servicing to qualified service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.
